Milton CAT RM 300 - Manual (Page 8)

8
Rotor Drive
Maximum production with high reliability. The mechanical rotor drive system provides
three rotor speeds for maximum performance in a variety of materials and cutting depths.
Hydraulically engaged clutch, high
torque mechanical transmission and
drive axle allows efficient and reliable
transfer of engine power to rotor and is
sized to handle tough cutting and deep
mixing.
Rugged drive chains provide efficient,
continuous power to the rotor. Single
strand heavy-duty chain resists
breakage.
Three rotor speeds for maximum
performance in a variety of materials
and cutting depths. First speed is used
primarily for pulverizing the material.
Second and third rotor speeds can be
used as blending or mixing passes.
High capacity rotor driveshafts and
maintenance-free universal joints.
Heavy-duty shear disc or optional
torque limiter protects rotor drive
components from torsional stress and
shock loads.
Rear Wheel Drive
Optional rear wheel drive includes a separate hydraulic pump and large displacement
motors on each rear wheel. The system propels the machine with all-wheel drive.
Two propel pump system: one pump is
dedicated to drive the front wheels,
while the second propel pump is
dedicated to drive the rear wheels.
Increased tractive effort for those tough
soil or reclamation jobs.
Flow divider control valve directs equal
hydraulic flow to each rear wheel to
provide all-wheel drive.
High torque large displacement motors
on rear wheels makes this a true four-
wheel drive machine.
Large rear tires with an aggressive
tread and large footprint propels the
machine easily in the most severe
applications.
Rear wheel drive feature can be turned
on by a switch on the operator’s
console when maximum tractive effort
is required.
