14 RM-300 specifications
Roll Over Protective Structure (ROPS)
is a two-post structure that bolts directly
onto flanges welded to the mainframe.
The structure meets ISO 3471. The
structure can be field installed.
Falling Object Protective Structure
(FOPS) that bolts directly to the ROPS
which provides Level 1 protection and
also serves as a sun canopy. The
structure meets ISO 3449. The structure
can be field installed.
Sliding Operator Station slides fully to
both sides of platform using hydraulic-
assist. Includes a rotating vinyl seat,
handrails, dual access ladders and
vandalism guards for both the front and
side control console.
Sliding Cab includes a rotating cloth
seat, sound absorbing headliner, left and
right side lockable doors, tinted glass,
air conditioning, heater/defroster, dual
front and rear windshield wipers and
rubber floor mat. The cab is also radio-
ready and includes a power converter,
antenna with cable, two speakers and a
headliner location for mounting.
Rear Wheel Drive propels the machine
with on-demand all-wheel drive in the
work mode to increase tractive effort.
Highly recommended for soil
stabilization applications. Includes
separate propel pump, two radial piston
hydraulic drive motors, flow divider and
free wheeling valve. The rear wheels
freewheel when rear wheel drive is not
engaged.
Automatic Rotor Depth Control. ECM
automatically controls rotor depth to a
preset cutting depth. Setting cutting depth
is easily accomplished first in manual
mode by a switch on the operator’s
console. Actual rotor height and depth
are displayed on the electronic control
panel. (Includes four mode steering.)
Four Mode Steering. ECM monitors
the position of the steering mode switch
and controls the rear wheels to provide
automatic crab and coordinated steering.
(Includes automatic rotor depth control.)
Hydraulically Operated Front Door
allows the operator to control the
opening of the front door from the
operator’s station. Offers better control
of gradation in reclamation and
increased versatility in soil stabilization
because the machine is able to work in
both directions.
Friction Torque Limiter protects rotor
drive train from high torque loads in the
event the rotor strikes an immovable
object. The limiter slips momentarily
without interrupting machine operation.
Working Light Package includes six
adjustable halogen floodlights, two
front-facing, two rear-facing and two
facing each rotor chamber door. Two red
tail lamps, eight amber and two red
reflectors are also included.
Roading Light Package includes two
front-facing headlights, two amber
running lamps, four amber turn
signal/hazard lamps and a slow moving
vehicle sign. Light package used for
highway transport purposes only.
Warning Beacon Light includes an
amber rotating beacon mounted on a
retractable pole and mount.
Mirror Package includes an adjustable
mirror mounted on both sides of the
machine for good visibility to the rear
and along the sides of the machine.
Umbrella provides sun and rain
protection for the operator and includes
a support shaft and mounting hardware.
Only for use on open platform machines
without ROPS or cab.
Water Spray System accurately adds
water to processed material. System
includes a operator interface panel,
hydraulic filter, EDC controlled
hydraulic pump, a 379 - 1895 liters
(100 - 500 U.S. gallons) per minute
vane-type centrifugal pump, in-line flow
meter, spray bar with nozzles and
hydraulically operated single valve
spray bar shut-off.
Powertrain Guard includes three bolt-
on steel guards to provide protection for
the engine crankcase and hydraulic
hoses at front axle area.
Universal Rotor is designed for use in
asphalt reclamation and features
breakaway bolt-on tool holders.
Maximum cutting depth is
457 mm (18").
Soil Rotor is designed for use in soil
stabilization and features weld-on tool
holders. Maximum cutting depth is 508
mm (20").
Optional Equipment
N ote: Some options listed may be an option in some areas and standard in others. Consult your dealer for specifics.
Tires
Front
28.1" x 26" 18-ply lug-type R-1
262 kPa (38 psi)
Rear
18.4" x 30" 12-ply lug-type R-1
221 kPa (32 psi)
Electrical
The 24-volt electrical system consists
of two maintenance-free Cat batteries.
Electrical wiring is color-coded,
numbered, wrapped in vinyl-coated
nylon braid and labeled with
component identifiers. The starting
system provides 1365 cold cranking
amps (cca). The system includes a
95-amp alternator.
Frame
Fabricated from heavy gauge steel
plates and structural steel tubing. Frame
joined to rear bolster with welded-in
trunion and spherical plain bearings to
allow rear bolster oscillation of 15º.
