C&H Technology PD42__07 - Manual (Page 3)

Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272 POW-R-BLOK
TM
www.pwrx.com Dual SCR / Diode Isolated Module
700 Amperes, Up to 1800 Volts
Revision Date: 09/28/2009
PD42__07
Absolute Maximum Ratings
Characteristics Conditions Symbol Units
Repetitive Peak Forward and Reverse Blocking
Voltage V
DRM
& V
RRM
Up to 1800 V
Non-Repetitive Peak Blocking Voltage
(t < 5 msec) V
RSM
V
RRM
+ 100V V
RMS Current AC Switch Configuration
(180
o
Conduction)
180
° Conduction, T
C
=74
°C
180 ° Conduction, T
C
=78 °C
180
° Conduction, T
C
=82
°C
180 ° Conduction, T
C
=86 °C
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
1775
1665
1550
1440
A
A
A
A
RMS Current Per SCR
(180
o
Conduction)
180
° Conduction, T
C
=74
°C
180 ° Conduction, T
C
=78 °C
180
° Conduction, T
C
=82
°C
180 ° Conduction, T
C
=86 °C
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
1256
1178
1100
1020
A
A
A
A
Average Forward Current Per SCR
(180
o
Conduction)
180
° Conduction, T
C
=74
°C
180 ° Conduction, T
C
=78 °C
180
° Conduction, T
C
=82
°C
180 ° Conduction, T
C
=86 °C
I
T(AV)
I
T(AV)
I
T(AV)
I
T(AV)
800
750
700
650
A
A
A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 25C, Vr = 0 60 Hz
50 Hz I
TSM
I
TSM
69,000
63,000 A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 25C, Vr = Vrrm 60 Hz
50 Hz I
TSM
I
TSM
46,000
42,000 A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 125C, Vr = 0 60 Hz
50 Hz I
TSM
I
TSM
60,000
54,750 A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 125C, Vr = Vrrm 60 Hz
50 Hz I
TSM
I
TSM
40,000
36,500 A
A
Peak Three Cycle Surge Current, Non-Repetitive 60 Hz, Tj = 125C, Vr = Vrrm I
TSM
32,100 A
Peak Ten Cycle Surge Current, Non-Repetitive 60 Hz, Tj = 125C, Vr = Vrrm I
TSM
25,200 A
I 2 t for Fusing for One Cycle
Tj = 125C, Vr = Vrrm
8.3 milliseconds
10 milliseconds
I 2 t
I 2 t
6.60 x 10
6
6.66 x 10
6
A 2 sec
A 2 sec
Maximum Rate-of-Rise of On-State Current,
(Non-Repetitive) Per JEDEC Standard 397 5.2.2.6 di/dt 400 A/ μs
Maximum Rate-of-Rise of On-State Current,
(Repetitive) Per JEDEC Standard 397 5.2.2.6 di/dt 150 A/
μs
Operating Temperature T
J
-40 to +125 °C
Storage Temperature T
stg
-40 to +150 °C
Max. Mounting Torque, M6 Mounting Screw 132
15
in. – Lb.
Nm
Max. Mounting Torque, M10 Terminal Screw 106
12
in. – Lb.
Nm
Module Weight, Typical 5.33 kg
11.75 lb
V Isolation @ 25C V
rms
3000 V
Information presented is based upon manufacturers testing and projected capabilities.
This information is subject to change without notice.
The manufacturer makes no claim as to suitability for use, reliability, capability,
or future availability of this product.
