Installation Guide
Power Monitoring
E50B1A, E50C2A, E50C3A
TM
E50C2A FDS E50C3A L
og
E50xxA REG.
R/W NV Format Units Scale Range Description
• 166 R NV UInt
Month /
Day
See Bytes
Most Significant Byte (MSB) Least Significant Byte (LSB)
Date & Time of the newest entry in the log.
After a power cycle, resets to:
Day 01 Month 01
Hour 00 Year (20) 00
Day 1-31 (0x01-0x1F) Month 1-12 (0x01-0x0C)
• 167 R NV UInt
Year /
Hour
See Bytes Hour 0-23 (0x00-0x17) Year 0-199 (0x00-0xC7)
• 168 R NV UInt
Minutes /
Seconds
See Bytes Seconds 0-59 (0x00-0x3B) Minutes 0-59 (0x00-0x3B)
• 169 R/W NV UInt
1-42, 146,
155-157,
257-336
Log Register Pointer 1 –
Default is 1 (Real Energy MSR)
Log Register Selection – Write the number of the 16 bit register to be logged.
To log a 32 bit value (such as accumulators and floating point values) two log
registers must be used, one each for the most and least significant register
(MSR & LSR).
• 170 R/W NV UInt
Log Register Pointer 2 –
Default is 2 (Real Energy LSR)
• 171 R/W NV UInt
Log Register Pointer 3 –
Default is 29 (Reactive Energy
MSR)
• 172 R/W NV UInt
Log Register Pointer 4 –
Default is 30 (Reactive Energy
LSR)
• 173 R/W NV UInt
Log Register Pointer 5 –
Default is 37 (Real Demand)
• 174 R/W NV UInt
Log Register Pointer 6 –
Default is 38 (Reactive Demand)
• 175 R/W NV UInt
Log Register Pointer 7 –
Default is 39 (Apparent Demand)
• 176 R/W NV UInt
Log Register Pointer 8 –
Default is 155 (Month/Day)
• 177 R/W NV UInt
Log Register Pointer 9 –
Default is 156 (Year/Hour)
• 178 R/W NV UInt
Log Register Pointer 10 –
Default is 157 (Minutes/Seconds)
Floating Point Data
• • 257/258 R NV Float kWh Real Energy Consumption (clear via reset register)
• • 259/260 R NV Float kWh Real Energy Consumption (clear via reset register)
• • 261/262 R Float kW Total Instantaneous Real Power
• • 263/264 R Float kVAR Total Instantaneous Reactive Power
• • 265/266 R Float kVA Total Instantaneous Apparent Power
• • 267/268 R Float Ratio 0.0-1.0 Total Power Factor (Total KW / Total KVA)
• • 269/270 R Float Volt Voltage, L-L, Average of 3 Phases
• • 271/272 R Float Volt Voltage, L-N, Average of 3 Phases
• • 273/274 R Float Amp Current, Average of 3 Phases
• • 275/276 R Float kW Real Power, Phase A
• • 277/278 R Float kW Real Power, Phase B
• • 279/280 R Float kW Real Power, Phase C
• • 281/282 R Float Ratio 0.0-1.0 Power Factor, Phase A
• • 283/284 R Float Ratio 0.0-1.0 Power Factor, Phase B
• • 285/286 R Float Ratio 0.0-1.0 Power Factor, Phase C
• • 287/288 R Float Volt Voltage, Phase A-B
• • 289/290 R Float Volt Voltage, Phase B-C
• • 291/292 R Float Volt Voltage, Phase A-C
• • 293/294 R Float Volt Voltage, Phase A-N
• • 295/296 R Float Volt Voltage, Phase B-N
• • 297/298 R Float Volt Voltage, Phase C-N
• • 299/300 R Float Amp Current, Instantaneous, Phase A
Modbus Point Map (cont.)
