INFORMATION BULLETIN - ABIB-0803r1 – D2000F, D2200F RECOMMENDED SERVICE PARTS STOCKING LIST
The material contained in this bulletin is product improvement information. Dana Corporation is not
committed to, or liable for, canvassing existing products.
Spicer Part-No.
Group
Ref
Code
Beam
Drop Part Description Notes
Recommended
Dealer Stocking
(Based on Fleet Size
of 10)
331435 Kingpin Kit
Used on 3.5" Drop Beam, same side
draw key design
2
220TR129-2 Tie Rod Assy - Complete Adjustment Range: 63.00" - 67.50" 1
220TR130 Tie Rod End - LH Straight End Design - 7.5" 2
220TR131 Tie Rod End - RH Straight End Design - 7.5" 2
220TR145-1 Tie Rod Arm - LH 1
220TR145-2 Tie Rod Arm - RH 1
220SA150-1 Steer Arm - LH 1
220SA148-1 Steer Arm - RH 1
331434 Kingpin Kit
Used on 5" Drop Beam, opposite side
draw key design
2
220TR114-1 Tie Rod Assy - Complete Adjustment Range: 63.00" - 67.50" 1
220TR118 Tie Rod End - LH Drop Style End Design - 12.69" 2
220TR119 Tie Rod End - RH Drop Style End Design - 12.69" 2
220SA140-1 Steer Arm - LH 1
220SA142-1 Steer Arm - RH 1
220TR145-5 Tie Rod Arm - LH 1
220TR146-5 Tie Rod Arm - RH 1
220SK138-2 Knuckle Assy - LH knuckles common to both designs 1
220SK139-2 Knuckle Assy - RH knuckles common to both designs 1
A and B
Spicer D2000F, D2200F Steer Axle Service Parts
3.5"
Beam
Drop
5.00"
Beam
Drop
A
B
Spicer Part-no Description Qty
220HC100 THRUST BEARING 2
220HP100-1 KEY-DRAW-INNER 2
220HP100-2 KEY-DRAW-INNER 2
1460HN100 BELLEVILLE WASHER 8
220HN103 DRAW KEY HEX NUT 4
160HS100-1 SHIM 2
160HS100-2 SHIM 2
160HS100-3 SHIM 2
160HD105 BUSHING 4
160HH100 SEAL-OIL 4
971010 INSERT - FOAM 4
971370 KNUCKLE CAP 4
1001414 GREASE FITTING-90DEG 4
220SC110 KNUCKLE PIN 2
331434 Kingpin Kit - 5" Drop Beam
Draw Key Design: Dual Draw Key-Opposite Side
Spicer Part-no Description Qty
220HC100 THRUST BEARING 2
220HP100-2 KEY-DRAW-INNER 4
1460HN100 BELLEVILLE WASHER 8
220HN103 DRAW KEY HEX NUT 4
160HS100-1 SHIM 2
160HS100-2 SHIM 2
160HS100-3 SHIM 2
160HD105 BUSHING 4
160HH100 SEAL-OIL 4
1001414 GREASE FITTING-90DEG 4
971010 INSERT - FOAM 4
971370 KNUCKLE CAP 4
220SC112 KNUCKLE PIN 2
331435 Kingpin Kit - 3.5" Drop Beam
Draw Key Design: Dual Draw Key-Same Side
