Navigation System 57
Driving to Your Destination
Map Screen Legend
Acura Dealer
School
Restaurant
ATM
Parking Lot
Post Office
Honda Dealer
Hospital
Grocery Store
Gas Station
Hotel/Lodging
Parking Garage
Freeway Exit Information
Landmark Icon - Generic (see page 64 )
Destination Icon (see page 63 )
Map Features
NOTE:
If you move the Interface Dial over an area (map
features shown above), the name is displayed on
the screen.
: Park
: Hospital
: Shopping Mall
: Golf Course
: Water Area
: Cemetery
: University
: Indian Reservation
: Airport/Stadium/Business
Map Scale Adjustment
(Mile or km per half-inch appears
only when you zoom in or out by
rotating the Interface Dial knob.)
(see page
62 )
NOTE:
See
Map Legend on the INFO screen ( Other ) for further explanation (see page 90 ).
Current Map Scale
(see page
62 )
Current Street
(see page
71 )
Vehicle Position
(see page
71 )
Breadcrumbs
(see
Off-road Tracking
on page 70 )
Direction of Destination (when en route)
(see page
59 )
Map Orientation
(see page
63 )
Distance to Destination (see page 59 )
Time to Destination (see page 59 )
Waypoint (see page 75 )
Blue Line
Calculated route
(see page
55 )
Map Menu (see page 59 )
(Push in on the Interface Dial to view.)
One-Way Traffic Icon
(1/20 mile scale only) (see page
64 )
Streets
(see
Map Overview on
page 6 , or Unverified Area
Routing on page 102 )
Interstates or Freeways
Verified Streets
Unverified Streets
No Entry Icon
