Acnodes MKP1602__MKCP 1614 - Manual (Page 12)

P.9 MKCP 1613/1614/1624
Specification Matrix IP Cat6 16 port KVM
MKCP1613 / MKCP1614 / MKCP1624
▀ KVM Port
Number of ports: 16
Connector: RJ-45
Connectivity: DVI-D / VGA connector dongle up to 40 meters (132 feet)
Cat6 / Cat5 cable
▀ Local Console
Monitor port: HDDB15-pin VGA, up to 1600 x 1200
Keyboard & mouse port: 2 x USB type connector for keyboard & mouse
▀ Cat6 Remote Console
Number of remote port: 1 / 2 / 1
Monitor port: DB15-pin VGA, up to 1600 x 1200
Keyboard & mouse port: 2 x USB type connector for keyboard & mouse
Remote I/O: RJ45 via Cat5 / Cat5e / Cat6 cable up to 1,000 feet
▀ IP Remote Console
Number of IP console: 1 / 1 / 2
User management: 15-user login, 1 x active user
Browser: Internet Explorer, Firefox, Safari
Security: SSL v3, RSA, AES, HTTP / HTTPs, CSR
IP Access: 1 x RJ45 Ethernet, 1 x DB-9 serial & 1 x USB port
Remote I/O: RJ45 via Cat5 / Cat5e / Cat6 cable up to 1,000 feet
▀ Expansion: Up to 128 servers by 8-level cascade
▀ Compatibility
Multi-platform: Mix PCs, SUNs, IBMs, HPs, DELLs Server
Support: Windows Vista / 2003 / XP / 2000, Linux, Netware, Unix
▀ Power
Input: 100~240VAC, 50 / 60Hz 0.5A via AC / DC cord
Option DC: 12V / 24V / 48V DC input
Consumption: Max. 24 Watt, Standby 5 Watt
▀ Regulatory Approval: FCC, CE
▀ Environmental
Operating: 0 to 50°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)
▀ Product Information
Dimension (W x D x H): 448 x 180 x 44 mm / 17.6 x 7.1 x 1.73 inch
Net weight: 4 kg / 9 lb
Power ON
■ Turn off all servers and KVM switches
■ Make sure all cables / connectors are properly connected
■ Recommend Power ON sequence is monitor, KVM switch finally computer
