EVOLUTION MK-7 MIDI KEYBOARD MANUAL

1.

General Guide

KEYBOARD

BACK PANEL

1.

WHEEL button

2.

SELECT button

3.

PITCH BEND +/- switches

4.

Numeric keys

5.

PROGRAM key

6.

BANK LSB key

7.

BANK MSB key

8.

WHEEL key

9.

SAVE key

10.

CHANNEL key

11.

OCTAVE key

12.

TRANSPOSE key

13.

+/- keys

14.

RESET-AC key

15.

GM-RESET

16.

MIDI OUT Connector
For connecting directly to PC sound card game port

17.

DC Jack
For connecting to AC/DC adapter. DC output 9V-1 2V, 1 50mA, centre positive.

18.

POWER switch

2.

Power Supply

2-1

DC Power - Batteries (not included)
This unit is powered by 6 “AA” (UM-3) size batteries. Weak batteries will result in poor performance. When
the power is getting weaker, replace the worn out batteries as follows:

1.

Remove the battery compartment cover and take out the batteries.

2.

Insert new batteries and make sure that the polarity is correct.

3.

It is advisable to replace all 6 batteries at the same time and not to mix batteries. Alkaline batteries are
recommended for maximum performance.

2-2

AC Power
You can also use AC adapter with the following specification: 9-12V DC output, 150mA, centre positive.

Note: Do not leave the adapter plugged in for long periods of time if the unit is not in use.

3.

Preparation
This unit’s MIDI OUT connector is specially for connecting to personal computers.
