43
Local Date/Time
This selection allows the user to set the local date and time.
To access the Local Date/Time option and set date and time:
1. From the Phone Configuration menu use the
or keys to access the
Local Date / Time option, then press SELECT key.
2. When “Enter Year” is displayed, enter the year (YYYY format), eg., 2003,
then press SELECT key.
3. When “Enter Month” is displayed, enter the month (1~12),
then press SELECT key.
4. When “Enter Day” is displayed, enter the day (1~valid max), then press
SELECT key.
5. When “Enter Hour” is displayed, enter the hour (0~23),
then press SELECT key.
6. When “Enter Minute” is displayed, enter the minutes (0~59), then press
SELECT key. The display returns to the Local Date/Time option.
• A data validation check is performed for each data field. If the date is not valid,
a warning message is displayed for one second.
• If SNTP server is enabled, date and time information is obtained from SNTP
server address configured by administrative user.
• When time is maintained locally, the telephone checks every 10 minutes for the
activation of an SNTP server and updates the local time if it is available.
• When the SNTP server request is successful, it automatically overwrites all
previous manual local date and time settings and updates the information from
the SNTP server.
• If an SNTP server is not available or it is disabled, the local time starts from
01/01/02 when the system is powered on.
Phone Configuration:
Local Date / Time
2/5
