660 Series Electric Start (Pony ES Only)
Ref.
Part Number
Description
1.
1186073
Carriage Screw 1⁄4-20 x 1.25
2.
1186211
Hex Nut 5⁄16-24
3.
1186309
Flange Screw 1⁄4-20 x .625
4.
1186389
Hex Locknut 1⁄4-20
5.
1901202
Cable (Ground Wire)
6.
725-04346
Wire Harness Assembly
—
—
With connector to large solenoid
stud (Red Wire)
—
—
With connector to small solenoid
stud (Red Wire)
—
—
With connector to solenoid
grounding screw (Red Wire)
—
—
With connector to engine ground
shut-off (Green Wire)
—
—
Plastic protector tube; wire terminal
7.
725-04346
Electric Start Harness
8.
686-04024
Battery Bracket Assembly
9.
710-0599
Self-tapping Screw 1⁄4-20 x .5
10.
712-3006
Hex Nut 1⁄4-20
11.
725-0157
Cable Tie
12.
725-0267B
Ignition Switch
13.
725-1706A
Battery 270 CCA
14.
736-0119
Lock Washer 5/16
15.
736-0147
Lock Washer #10
16.
736-0607
External Lock Washer 5⁄16
17.
GW-2614
Keyswitch Clamp
18.
GW-96510
Cable (Solenoid to Starter Motor)
19.
GW-96514
Solenoid (Incl. Nuts and Washers
for Cables and Wires)
20.
GW-97020
Insulating Boot
