December 16, 2011 7014-179D Page 45
CB 1200 Pellet Stove
Service Parts
12/11
R
CB1200M-MBK
Beginning Manufacturing Date: April 2009
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
ACCESSORIES
Collar, Offset, Top Vent 812-3570
Damper, 3 Inch - Tall Vertical Installs Only PEL-DAMP3 Y
Damper, 4 Inch - Tall Vertical Installs Only PEL-DAMP4
Log Set 811-0592
Log, Front 7027-219
Log, Rear Left 7027-221
Log, Rear Right 7027-220
Outside Air Kit, Floor 811-0570
Outside Air Kit, Rear 811-0872
Channel, Air Intake 413-7040
Cover, Outside Air Kit, Floor 411-1071
Hose, Alum Flex, 2 Inch x 3 Ft Qty. 3 Ft. Req. 200-0860
Outside Air Cap Assembly 7001-044
Outside Air Collar Assembly 7001-045
Trim Plate, Outside Air Kit 412-7100
Smart-Batt Il 841-0970
Smart-Stat Il 841-0960
Thermostat, Mechanical 812-3760 Y
Thermostat, Programmable 811-0520
Top Vent Adapter TPVNT-1
Vent Adapter, 90, Cleanout 811-0610
Vent Adapter, Rear 811-0620
FASTENERS
Avk Rivnut Repair Kit - 1/4-20 & 3/8-16 Rivnut Tool RIVNUT-REPAIR Y
Bolt, Shoulder, 5/16 X 1/4-20 Pkg of 20 223-0170/20 Y
Ceramic Nuts, (Igniter) Pkg of 12 812-0730/12 Y
Nut, Keps Lock, 8-32 Pkg of 40 226-0060/40 Y
Nut, Ser Flange Small 1/4-20 Pkg of 24 226-0130/24 Y
Nut, Wing, 8-32 Pkg of 24 226-0160/24 Y
Screw, Pan Head Philips 10-32 X 3/8 Pkg of 40 21799A/40 Y
Screw, Pan Head Philips 8-32 X 3/4 Pkg of 24 229-1100/24 Y
Screw, Sheet Metal #8 X 1/2 S-Grip Pkg of 40 12460/40 Y
Washer, 1/4 Sae Pkg of 24 28758/24 Y
Washer, Sae, 3/8 Pkg of 3 ea. 832-0990 Y
