RedMax TR2301S - Manual (Page 59)

59 59
Key# Part Number Description Q'ty
1 848E488100 CARBURETOR ASSY WYL-221 1
2 1794-81450 • BODY ASSY 1
3 3306-81380 • • SCREEN 1
4 3356-81310 • • VALVE, inlet 1
5 1794-81270 • • SPRING 1
6 1850-81220 • • SCREW 1
7 3310-81250 • • PIN 1
8 3310-81230 • • LEVER 1
9 1850-81490 • BODY, purge 1
10 1850-81520 • COVER, pump 1
11 1751-81510 • PUMP, priming 1
12 4810-81260 • DIAPHRAGM 1
13 1850-81470 • GASKET 1
14 8488J13600 • JET #36 1
15 1751-81130 • RING 1
16 1881-81140 • SWIVEL 1
17 1751-81240 • O-RING 1
18 4810-81410 • GASKET 1
19 1065-81420 • DIAPHRAGM, pump 1
20 5850-81110 • SCREW 2
21 1850-81530 • SCREW 4
Key# Part Number Description Q'ty
Fig.3 CARBURETOR TR2301S
