RICOH Pro C900
Color Production System
Improve Capacity and Build Your Business
productivity
GB5000 Perfect Binder*
Expand your repertoire to include inline perfect-
bound books up to 100 sheets (200 impressions).
This finisher automatically trims collated pages
(three sides or one side) and applies the perfect
binding without operator intervention—so you
can reduce labor costs.
GBC StreamPunch ™ III*
This interchangeable die punch unit rapidly
produces punched documents in a variety of
binding styles—without labor-intensive manual
punch operations. Inline punching eliminates
additional production steps, saving time and
eliminating costly errors.
RB5000 Ring Binder*
The Ring Binder automates the entire binding
process, so operators can prepare incoming jobs
while additional jobs are being ring-bound. So,
you can improve productivity and reduce the
risk of bottlenecks. Choose two ring sizes for
documents up to 50 or 100 sheets.
Engineered for Reliable Performance RICOH Pro C900
System Specifications
Take a Closer Look at the RICOH Pro C900
Build the perfect digital color production system as your company’s needs grow
using the flexible RICOH Pro C900 modular components.
Main Unit
Main Unit Base Pro C900
Configuration Base Unit includes Plotting Engine,
EFI Fiery Print Controller,
2 x 1,000-Sheet Tandem Tray,
1 x 500-Sheet Tray and
10.4" Operation Panel
Printing Process Dry electrostatic transfer with internal
transfer belt; 4-drum method
Maximum Print Resolution 1200 dpi
Output Speed
8.5" x 11": 90 pages-per-minute
in B&W and full-color
Warm-Up Time Less than 420 seconds
Optional Input Trays:
RT5000 Letter Large Tray 1: 1,000 sheets
Capacity Tray Tray 2: 1,000 sheets
Tray 3: 2,550 sheets
Total: 4,550 sheets
RT5020 Large 13" x 19.2" Large Capacity Tray:
Capacity Tray 2 x 2,000-Sheet Trays Total:
4,000 sheets
BY5000 Muti-Bypass Tray 500-Sheet Multi-Bypass Tray Unit:
Total: 500 sheets
Maximum Input Capacity 11,000 sheets (fully configured)
Optional Output Stacking
Devices:
SR5000 Finisher 3,000 sheets (100-sheet stapling)
SK5000 High-Capacity 5,000 sheets (up to two units can
Stacker be added; roll-away media cart
included)
Maximum Output 13,000 sheets (fully configured)
Media Capacity
Media Size
(Standard Input Trays): Tray 1: 8.5" x 11" (tandem),
11" x 17"with optional Tandem
Tray Converter
Tray 2: 5.5" x 8.5" – 13" x 18"
Media Weight
(Standard Input Trays): Tray 1: 16 lb. Bond – 80 lb. Cover
Tray 2: 16 lb. Bond – 80 lb. Cover
Dimensions (W x D x H) 49.2" x 43.3" x 56.7"
Weight 1,543.2 lbs. (700 kg) or less
Power Requirements 240V, 24A
Maximum Power Less than 5,500W
Consumption
EFI ™ Fiery ® Print Controller Specifications
(Standard)
CPU Intel Core Duo 2.16 GHz
Memory 2 GB
Hard Disk Drive 500 GB (250 GB x 2)
Operating System Windows XP
Fiery System Version Fiery System 8.0 Release 2
Page Description PCL5c, PCL6, Genuine Adobe ®
Languages PostScript ® 3 ™
Network Interface Ethernet 1000/100/10BaseT
Network Protocols TCP/IP (IPv4, IPv6), Apple Talk, SMB
Client Operating Windows 2000/2003/XP/Vista
System Support Mac OS/X v10.3.9 or later
Standard Utilities:
Print Submission & EFI Driver, EFI Command WorkStation
Management (PC & Mac), Fiery WebTools,
EFI Hot Folders, EFI Virtual Printer,
Macintosh Print Center Plug-Ins,
Rush Printing, Print/Process Next,
Advanced Job Re-Order, Suspend
On Mismatch, Quick Doc Merge,
Schedule Print
Color Management EFI Fiery ColorWise, Fiery Graphic
& Proofing Arts Package
Imposition & Document Mixed Media, Paper Catalogue,
Assembly
Tab Shift, Insert Tab, Booklet
Maker, EFI Impose, Fiery Edition
Variable Data Printing PPML, EFI Fiery FreeForm, Fiery
VDP Resource Manager, Creo VPS
Additional Utilities Web Image Monitor, Ricoh
@Remote
Optional Utilities:
Color Management Fiery Graphic Arts Package Premium
& Proofing Edition, EFI Color Profiler Suite V2.2
Imposition & Document EFI Compose Fiery Edition
Assembly
Color Measurement ES-1000 Color
Spectrophotometer
Security Specifications
SMTP v3 Authentication, POP before SMTP, PDF Encryption,
User Codes
Optional Input and Finishing Accessories
RT5000 Letter Large Capacity Tray
Media Capacity Tray 1: 1,000 sheets
Tray 2: 1,000 sheets
Tray 3: 2,550 sheets
Media Size Up to 8.5" x 11"
Media Weight Top Two Trays: 16 lb. Bond –
80 lb. Cover
Bottom Tray: 16 lb. Bond –
60 lb. Cover
LCIT RT5020 13" x 19.2" Large Capacity Tray*
Media Capacity 2 x 2,000-Sheet Trays
Media Size 5.5" x 8.5" – 13" x 19.2"
Media Weight 16 lb. Bond – 110 lb. Cover
*For tandem connection, Bridge Unit BU5000 is required for 13" x 19.2"
Large Capacity Tray. Up to two units can be connected.
BY5000 500-Sheet Multi-Bypass Tray Unit
Media Capacity 500 sheets
Media Size 5.5" x 8.5" – 13" x 19.2"
Media Weight 16 lb. Bond – 80 lb. Cover/
120 lb. Index
CI5010 2-Tray Cover Interposer
Stack Capacity 2 x 200-Sheet Trays
Media Size 5.5" x 8.5" – 13" x 19.2"
Media Weight 17 lb. Bond – 80 lb. Cover
SR5000 3,000 Sheet Finisher/Stapler
Media Size 5.5" x 8.5" – 11" x 17";
Up to 13" x 19.2"
Media Weight Proof Tray: 16 lb. Bond –
80 lb. Cover
Shift Tray: 16 lb. Bond –
110 lb. Cover
Stack Capacity Proof Tray: 500 sheets
(8.5" x 11" or smaller)
Shift Tray: 3,000 sheets
(8.5" x 11" or smaller)
Staple Capacity 100 sheets: 8.5" x 11"
50 sheets: 8.5" x 14" or smaller
Z-Fold: 10 sheets
Staple Positions Top, Bottom, 2 Staples, Top-Slant
Finisher Accessories Hole Punch Unit (2 or 3 holes)
BK5000 Saddle Stitch Unit
Media Size Without Z-Fold: 5.5" x 8.5" –
12" x 18"; Up to 13" x 19.2"
With Z-Fold: 8.5" x 11", 8.5" x 14",
11" x 17"
Media Weight 16 lb. Bond – 110 lb. Cover
Staple Capacity 15 sheets (20 lb. Bond)
Stack Capacity After 30 sets
Saddle Stitch
Punch Unit PU5000NA For 3/2 hole punch
Punch Unit PU5000SC For 4 hole punch
GB5000 Perfect Bind Unit
Booklet Size Width: 7.81" x 11.69"
Length: 5.5" x 8.5"
Media Weight 24 lb. Bond – 110 lb. Cover
Capacity 10 – 200 sheets (400 pages in
Duplex mode)
Stack Capacity 7 sets (100 sheets per set)
Cover Interposer Tray 2 x 200-Sheet Trays
Type GB5000
Transit Pass Unit For perfect bind*
Type GB5000
*Transit Pass Unit Type GB5000 is required.
ZF4000 Z-Fold Unit
With Shift Tray and Media Size: 8.5" x 11", 8.5" x
Proof Tray 14", 11" x 17" SEF
Stack Weight: 17 – 20 lb. Bond
With Staple Tray Media Size: 11" x 17"
Stack Weight: 17 – 20 lb. Bond
BK5010 Production Level Booklet Maker*
Maximum Booklet 30 sheets (120 pages)
Capacity
Finishing Speed Maintains rated engine speed of
90 ppm
Supported Media Size Width: 8.1" – 12.6"
Length: 10.8" – 18"
Supported Media Weight 16 lb. Bond – 172 lb. Index**
Optional Accessories TR5010 for face trimming
BF5010 for square book folding
CF5010 for cover feeding/
interposing/Rail Kit
*Manufactured by Plockmatic International AB.
**Booklet Maker supports up to 172 lb. Index in offline mode only. The
Pro C900 supports up to 80 lb. Cover online when combined with the
Booklet Maker.
GBC StreamPunch ™ III Finisher
Punch Type Customer-replaceable die sets (7)
Supported Media Size 8.5" x 11" LEF (11" side only)
RB5000 Ring Bind Unit
Media Size 8.5" x 11"
Media Weight 16 lb. Bond – 80 lb. cover
Bind Capacity 2 – 100 sheets
Stack Capacity Binding Mode: 11 sets (100 pages
per set)
Punching Mode: 50 sets
Ring (Consumables) Ring Bind Element for 50 sheets
Ring Bind Element for 100 sheets
Ring Opener Type A
SK5000 High-Capacity Stacker*
Media Sizes 5.5" x 8.5" – 11" x 17";
Up to 13" x 19.2"
Media Weight 16 lb. Bond – 110 lb. Cover
Stack Capacity 5,000 sheets
Roll-Away Cart Type 5000
*Up to two units can be connected.
Additional Accessories
Tab Sheet Unit, 11" x 17" Tandem Tray Converter, Optional
Counter Interface Unit Type A
Consumables
Cyan, Magenta, Yellow, 72,000 pages yield per bottle
Black Toner*
*Yields based on 5% coverage.
For maximum performance and yield, we recommend using genuine Ricoh
parts and supplies.
*Please contact your RICOH Pro C900 Sales Representative for availability.
Heavy Media Support
The RICOH Pro C900 can handle heavy media
at its full rated speed of 90 pages-per-minute.
Easy Toner Replacement
Replace toner on the fly with ease. Simply
load a Toner Bottle into the loading slot,
and slide the bottle in.
Status Light
Check the system at-a-glance with the status indicator light.
Vast Media Capacity
Load the system once and run for hours
without interruption. With all options, the
system holds up to 11,000 sheets and
handles output up to 13,000 sheets.
Large Capacity Tray
With two drawers that each hold up to 2,000
sheets, including sizes up to 13" x 19.2", the
RT5020 Large Capacity Tray* allows you to
reproduce full-bleed 11" x 17" documents
while preserving crop marks and borders.
*A total of two 13" x 19.2" LCTs can be added for a total
of 4,000 sheets.
Intuitive Operation Panel
Use the clear, easy-to-read Operation Panel to gain direct access to the Job
Queue and other advanced functions of the system’s EFI
™ Fiery ® print controller.
Trained Customer Replaceable Units
Trained Customer Replaceable Units (TCRUs) enable trained operators
to replace key hardware components quickly, to maximize uptime.
@Remote ™
Ensure accurate, timely meter reads and billing. The
Ricoh @Remote
™ service solution automatically collects
device data and reports media and toner alerts.
EFI ™ Fiery ® Print Controller
Establish end-to-end control over digital file
processing at every stage of production with
integrated workflow utilities from EFI
™ Fiery ® .
High-Capacity Stacker (not shown)
Leverage your current investment in offline finishing with the optional SK5000 High-Capacity
Stacker, which holds up to 5,000 sheets. Add up to two units with a roll-away cart to easily
transport 10,000 sheets of neatly stacked output for inline finishing, packing and distribution.
Versatile Finishing Options
The RB5000 Ring Binder and SR5000
3,000 Sheet Finishers are just some
of the numerous options you can
use to help operators complete
more jobs inline and reduce the
need for manual finishing.
workflow
speed
