Getting Started
4
1
8.
{Clear Modes} key
Press to cancel the current settings.
9.
On indicator
This indicator lights when the operation
switch is turned on.
Important
❒ Do not turn off the main power
switch while the On indicator stays
lighted or is blinking. Neglecting
this may damage the hard disk.
Note
❒ If the main power switch is on even
when the On indicator is off, the ma-
chine will receive a fax document.
10.
Main power indicator
This indicator lights when the main pow-
er switch is turned on. See “Turning On
the Power”, General Settings Guide.
11.
Operation switch
Press to turn the power on (the On indi-
cator lights). To turn the power off, press
this switch again (the On indicator goes
off). See p.202 “Turning Off the Main
Power / In the Event of Power Failure”,
Facsimile Reference
Note
❒ The Operation switch does not func-
tion when the [User Tools / Counter / In-
quiry]
display is shown.
12.
Data In indicator
Blinks when transmission, printing, stor-
ing to Document Server are performed
with using the LAN-Fax Driver.
13.
Receive File indicator
Lights when a document other than a
Confidential Reception or Memory Lock
file is received. See p.85 “Substitute Re-
ception”, Facsimile Reference
Also lights when a document is received
if the Reception Setting is set to Store. See
p.195 “Storing or Printing Received Doc-
uments”, Facsimile Reference
14.
Function status indicators
• When lit green, the corresponding function
is active.
• When lit red, the corresponding function
is interrupted. Press the respective key,
and then follow the instructions that
appear on the screen.
15.
Function keys
Press the {Copy}, {Document Server}, {Fac-
simile}
, {Printer}, or {Scanner} key to acti-
vate the respective function. The display
content changes accordingly.
The indicator for the selected function
lights up.
16.
{Start Manual RX} key
Press when Manual Reception is set. See
p.53 “Receiving a Fax in Manual Recep-
tion Mode”.
17.
{On Hook Dial} key
Press to dial while listening to the speak-
er tone. See p.57 “On Hook Dial”, Facsim-
ile Reference
18.
{Pause/Redial} key
Pause:
Inserts a pause when you are dialing or
storing a fax number. A pause cannot be
inserted as the first digit. See p.36 “Pause”.
Redial:
Press to redial one of the last ten numbers.
See p.47 “Redial”, Facsimile Reference
19.
{Tone} key
Press to send tonal signals down a pulse
dialing line. See p.36 “Tone”.
20.
Number keys
Use to dial fax numbers, or enter the number
of copies.
21.
{#} key (Enter key)
Registers entered contents or settings.
22.
{Clear/Stop} key
Clear:
Cancels entered numbers or characters.
Stop:
Interrupts the current operation (trans-
mission, scanning, copying, or printing).
