69
AC 120V 60Hz
Operation: 110W
Stand by: 4W
59.5 lbs (27.0 kg)
Width : 22-9/16 inches (573 mm)
Height : 20-3/8 inches (517 mm)
Depth : 19-1/8 inches (485 mm)
In: 1 Vp-p/75 ohm
Out: 1 Vp-p/75 ohm
In: –8 dBm/50K ohm
Out: –8 dBm/1K ohm
20Hz to 20,000Hz
More than 90 dB
20 inches (508 mm diagonal)
Quartz PLL Frequency Synthesized
VHF
2-13
UHF 14-69
CABLE 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-125 (100)-(125)
01 (5A)
VHF/UHF In 75 ohm coaxial
1-13/16" (46 mm) x 3-7/8" (99 mm), 8 ohm x 2
1.5W + 1.5W
4 Rotary Heads
Hi-Fi Sound - 2 Tracks / MONO Sound - 1 Track
Approx. 1 minute and 48 seconds (with T-120 Cassette Tape)
NTSC
DVD (12 cm, 8 cm), CD (12 cm, 8 cm)
DVD: 4Hz - 22KHz/CD: 4Hz - 20KHz
90 dB
0.06%
Below Measurable Level
Video : (RCA) 1 Vp-p/75 ohm
Audio : (RCA) –12 dBm/1K ohm
Digital Audio : 0.5 Vp-p/75 ohm
CD :
Wavelength: 770 - 800 nm
Maximum output power: 0.7 mW
DVD : Wavelength: 645 - 660 nm
Maximum output power: 0.5 mW
Remote control x 1
Batteries (AAA) x 2
Specifications
GENERAL
Power supply:
Power consumption:
Weight:
Dimensions:
Inputs/Outputs:
Video:
Audio:
Hi-Fi frequency response:
Hi-Fi dynamic range:
TELEVISION
Picture tube:
Tuner type:
Receiving channels:
Antenna input:
Speaker:
Audio output power:
VCR section
Video head:
Audio track:
F.FWD/REW Time at 25˚C (77˚F):
DVD section
Signal system:
Applicable disc:
Frequency response:
S/N Ratio:
Harmonic distortion:
Wow and flutter:
Output:
Pickup:
ACCESSORIES:
