Reference Manual for the Model DM602 ADSL Modem
Advanced Configuration of the Modem 5-3
Click on the “Show Statistics” button to display modem usage statistics, as shown in Figure 5-2
below:
Figure 5-2. Show Statistics screen
This screen shows the following statistics:.
Table 5-2. Router Statistics Fields
Field Description
Port The statistics for the ADSL WAN (Internet) and LAN (local) ports.
Status The link status of the port.
TxPkts The number of packets transmitted on this port since reset or manual clear.
RxPkts The number of packets received on this port since reset or manual clear.
Poll Interval Specifies the intervals at which the statistics are updated in this window. Click on Stop
to freeze the display.
