Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
48 VMD4544 LOADING SECTOR GEAR ASS'Y 1
1 VXA7038 MOTOR BRACKET ASS'Y 1 49 VMB2948 SPRING 1
1-1 VEM0726 MOTOR ASS'Y 1 (M) 50 VMC1652 T PORT GUIDE 1
1-2 EYHS77Y7 DEW SENSOR ASS'Y 1
1-3 VEK8982 FG SENSOR 1
1-4 VXA6656 CLEANER SOLENOID ASS'Y 1
1-4A VSJ0226 CLEANER SOLENOID 1 (M) 71 XQN2+A3 SCREW 1
1-5 VMM0441 CLEANER ROD 1 72 XQN2+A2FJ SCREW 4
1-6 VMB3454 CLEANER SPRING 1 73 XQN2+CF3FJ SCREW 7
1-7 VES0925 MODE SW ASS'Y 1 (M) 74 XYN2+J7FJ SCREW 1
1-8 VDG1426 WORM WHEEL 1 75 XQN2+A5 SCREW 2
1-9 VXP2029 WORM 1 76 VMX0967 CUT WASHER 5
1-10 VED0468 PRE CTL HEAD 1 ASS'Y 1 (M) 77 XQN16+A2FJ SCREW 3
1-11 VXA6737 PRE CTL HOLDER ASS'Y 1 78 XVE2B12FP HEX SCREW 1
1-12 VMS5987 AZIMUTH SLEEVE 1 79 XVE2B4FZ HEX SCREW 2
1-13 VMB2937 A/C HEAD ADJUST SPRING 1 80 XWA2B WASHER 2
1-14 XWG2 WASHER 1 81 XWG2A5 WASHER 3
1-15 XVE2B10FP SCREW 1 82 XXE2A6FP HEX SCREW 2
1-16 XXE2A6FP HEX SCREW 1 83 XYN2+J5FJ SCREW 2
1-17 XVE2B6FP HEX SCREW 1 84 VMX1599 CUT WASHER 3
2 VED0466 A/C HEAD 1 ASS'Y 1 (M) 85 XQN2+CF4FJ SCREW 2
3 VMA0F40 HORIZONTAL FIX BASE 1 86 VMX1061 WASHER 5
4 VXA6658 HIGHT FIX BASE 1 87 XYN2+C5FJ SCREW 4
5 VMS5987 AZIMUTH SLEEVE 1 88 VMX2027 CUT WASHER 1
6 VMB2937 A/C HEAD ADJUST SPRING 1 89 XWGV2Y4G WASHER 1
7 VHN0365 NYLON NUT 1 90 XUC12FP E-RING 2
8 VMA0F93 CABLE GUIDE 1 91 XWGV15Z32G WASHER 2
9 VMA0E98 SOLENOIDE ANGLE 1 92 XQN2+B3FJK SCREW 3
10 VSJ0227 PINCH SOLENOID 1 (M) 94 VMX0653 CUT WASHER 1
11 VMA0E90 SOLENOID BASE 1 95 XYN26+C5FJ SCREW 3
12 VXA7970 CYLINDER ADAPTOR U 1 96 XQN2+C4FJ SCREW 2
13 VDG1434 EM GEAR 1 * VXY1870Z1 MECHANICAL CHASSIS ASS'Y 1 (M)
14 VDG1437 CAM CONNECTION GEAR B 1
15 VMX2993 EM SLEEVE 1
16 VMB3440 EM GEAR SPRING 1
17 VDG1423 CAM CONNECTION GEAR A 1
18 VXP2037C EMARGENCY CONNECTION GEAR 1
19 VXA7523 S4 POST BASE ASS'Y 1 (M)
20 VXL3165 S TENSION ARM ASS'Y 1 (M)
21 VDG1438 TENSION LEG GEAR 1
22 VDG1424 MAIN CAM GEAR 1 (M)
23 VXA6647 S LOAD SECTOR GEAR 1
24 VDG1422 S CONNECTION GEAR 1
25 VXA7558 EM ROD ASS'Y 1
26 VEK8936 LED ASS'Y 1
27 LMHD16064 SCREW 4
28 VXA6700 TENSION LEG SECTOR GEAR 1
29 VXA6644 TENSION SENSOR ASS'Y 1
30 VXL3164 T5 ARM ASS'Y 1 (M)
30-1 VXL2989 T5 DRIVE LEVER A 1
30-2 VXL2991 T5 DRIVE LEVER B 1
30-3 VMB3436 T5 CHARGE SPRING 1
30-4 VMX2982 T5 ARM SLEEVE 1
31 VMB3418 T5 THRUST SPRING 1
32 VMD3910 TENSION BASE 1
33 VMB3434 A/C HIGHT SPRING 1
34 VXA6703 PINCH ELEVATOR ASS'Y 1
35 VXA7886C T LOADING ASS'Y 1 (M)
35-1 VMB3426 T-LOADING SPRING 1
35-2 VDG1428 T-LOADING GEAR 1
36 VXA7885C S LOADING ASS'Y 1 (M)
36-1 VMB3425 S LOADING SPRING 1
36-2 VDG1427 S LOADING GEAR 1
37 VXL3008C SOLENOID TURN ARM U 1
38 VML3520 SLENOID CONNECTION ARM 1
39 VXL3002 PINCH TURN ARM 1
40 VXL3163 T6 ARM ASS'Y 1 (M)
41 VXL3011C ELEVATOR DRIVE ASS'Y 1
 42 VEG1501 CYLINDER UNIT 1 (M)
42-1 VMD3885 CAP 1
43 VEM0717 CAPSTAN ASS'Y 1 (M)
44 VXL3028 CLEANING ARM ASS'Y 1 (M)
45 VXQ0439 SCREW 6
46 VXL3040 PINCH ARM ASS'Y 1 (M)
47 VMB3418 T5 THRUST SPRING 1
MECHANICAL CHASSIS ASSEMBLY (1)
MPL-2
