Pentax K20D - Manual (Page 5)

K20D Main Specifications
Effective Pixels approx.14.6 megapixels
Image Sensor Total pixels approx.15.07 megapixels
Type CMOS with a primary colour filter
Size 23.4mm x 15.6mm
Colour Depth 8 bit (JPEG) or 12 bit (RAW)
Recorded Pixels JPEG: [14.6M] 4672 x3104 pixels, [10M] 3872 x 2592 pixels, [2M] 1824 x 1216 pixels
RAW: [14.6M] 4672 x 3104 pixels
Sensitivity (Standard output sensitivity) Auto, Manual : ISO100 - 3200 (1EV steps or 1/2EV steps) can be expand to ISO6400, Bulb mode: up to ISO1600
Recording Formats RAW(Original), JPEG (Conforms to Exif 2.21), Conforms to DCF (Design rule of Camera File system)2.0
Image Formats Compressed: JPEG - Baseline (★★★★: Premium ,★★★: Best , ★★: Better, ★: Good) , RAW+JPEG : available
Compressed: RAW (PEF)
Non-compressed: RAW (DNG)
Storage Media SD , SDHC memory card
White Balance Auto, Daylight, Shade, Cloudy, Tungsten Light, Fluorescent Light (W, D, N), Flash, Manual setting, with WB fine adjustment
Viewfinder Type Pentaprism type
Focusing screen Natural-Bright-Matte II focusing screen
Field of view approx. 95%
Magnification approx.0.95X (with 50mm F1.4 lens, infinity, -1m -1 )
Diopter adjustment approx. -2.5 - +1.5m -1
LCD Monitor Type TFT colour LCD monitor, brightness adjustable, Colour adjustable, Wide angle view
Size 2.7 inch
Dots approx. 230,000 dots
Live View TTL by Image sensor
Field of view approx. 100%
Display Enlargement (4X, 8X) , Grid pattern
Preview Method Live View, Digital preview, Optical preview
Playback One Image, Two Images, Index (4 or 9 or 16 thumb nails), Enlargement (up to 32X, scroll available), Image Rotation,
Folder view, Slideshow, Histogram, Bright/Dark area
Digital Filter B&W (4 type), Sepia (3 type), Colour (18 type), Colour extract (6 type), Soft (three-level amount adjustable), Illustration,
HDR (3 type), Slim (+/- 8 level amount adjustable), Brightness (+/- 8 level amount adjustable)
Focusing System Type TTL Phase-matching 11-point wide autofocus system (SAFOX VIII)
Focus Mode AF-single (with focus lock); AF-continuous available*
Manual focus
Focus Point Auto, Select, Center
AF assist lamp available (by Built-in Flash)
Image Stabilizer Type Image sensor shift mechanism , Max 4 stops
Dust Removal Type Image sensor moving mechanism and SP coating with Dust Alert
Exposure Control Metering System TTL open-aperture 16-segment metering (coupled with lens and AF information)
Metering Mode (1) Multi-segment metering (2) Center-weighted metering (3) Spot metering
Exposure Range EV 0 - 21 (at Standard Output Sensitivity 100 with 50mm F1.4 lens)
Modes (1) Green, (2) Program AE, (3) Sensitivity-Priority AE, (4) Shutter-Priority AE, (5) Aperture-Priority AE,
(6) Shutter and Aperture Priority AE, (7) Metered Manual, (8) X speed, (9) Bulb
Exposure Compensation ±3 EV (0.5EV steps) , ±2 EV (0.3EV steps)
Auto-bracketing 3 or 5 frames within range of ±0.5EV, ±1.0EV, ±1.5EV, ±2.0EV (0.5EV steps) or ±0.3EV, ±0.7EV, ±1.0EV, ±1.3EV, ±1.7EV,
±2.0EV (0.3EV steps)
AE Lock available
Shutter Shutter Type Electronically controlled vertical-run focal plane shutter
Shutter Speed 1/4000 - 30 sec. and bulb
Drive Modes Single-frame, Continuous (Hi, Lo), Burst, Self-timer (12s, 2s), Remote control (0s, 3s), Remote control continuous,
auto bracket, extended bracket and Multi-exposure
Continuous shooting approx. 3fps, sequence: until 38 frames (JPEG and continuous (Hi)),14 frames (RAW(PEF)),16 frames (RAW(DNG))
approx. 2.3fps, sequence: until the memory card becomes full (JPEG and continuous (Lo)),14 frames (RAW(PEF)),16 frames (RAW(DNG))
Burst mode approx. 21 fps, sequence: 115 frames (1.6M ★★★ JPEG)
Built-in Flash Type Built-in retractable P-TTL pop-up flash
Guide number approx. 13 (Standard Output Sensitivity 100/m)
Angle of view coverage 28mm wide-angle (equivalent to 35mm)
Flash Synchronization Hot shoe, X-sync socket, sync-speed: 1/180 sec., P-TTL, high-speed-sync, wireless-sync with PENTAX dedicated flash
Data Folder Folder Name Date (100_MMDD･･･) / PENTX (100PENTX, 101PENTX･･･) ,
File Name Standard / User customize
Power Sources Rechargeable D-LI50 lithium-ion battery
Optional AC adapter also available.
Battery Life Number of recordable images approx. 530 *1 (50% use Flash) , approx. 740 *2 (Normal Recording)
Playback time approx. 330 minutes *2
Interfaces USB2.0 (HI-SPEED)/Video , DC input , Cable switch, X-sync socket
Lens Mount PENTAX K
AF2
bayonet mount
Usable Lens PENTAX K
AF2
-, K
AF
-, and K
A
-mount lenses.
* Power zoom function available. K-mount lenses usable with restrictions. S-mount lenses,
67/645 lenses usable with adapter and with restrictions.
Dimensions approx. 141.5(W) x 101(H) x 70(D)mm (5.6 x 4.0 x 2.76 inches)
Weight approx. 715g (25.2 oz.) without battery and SD memory card.
approx. 800g (28.2 oz.) loaded and ready with battery and SD memory card
*1 Recording capacity shows approximate number of shots recorded during CIPA-compliant testing. Actual performance may vary depending on operating conditions.
*2 According to the result of PENTAX in-house testing.
