Installation iii (joist mounting) – Panasonic FV-08VKML2 User Manual
Page 12
(FV-08VKML2)
(FV-08VKSL2)
Screw driver
Screw
(ST4.2X12)
II
2 Long screws
(ST4.2X20)
Screw
(ST4.2X12)
II
2 Long screws
(ST4.2X20)
4 Long screws (ST4.2X20)
Machine screw
Plug connector
Receptacle
Fig.11
Fig.12
Fig.13
Fig.14
I
-joist
Suspension
bracket
III
INSTALLATION
(JOIST MOUNTING- ) CONTINUED
INSTALLATION
( -JOIST MOUNTING)
6. Secure the fan body to adaptor by using machine
screw and plug connector to receptacle (Fig.11)
7. Secure the suspension bracket to joists by using
long screws (ST4.2X20) and secure it to fan body by
using screw
(ST4.2X12) in vertical direction (Fig.12)
II
8. Follow steps 7 to 12 of Installation (page 10) to
complete the installation work.
I
C1
C2
C3
C4
Suspension bracket
The suspension bracket
can comply with
different kind of -joists.
III
III
I
1. Before installation, secure the lighting unit to fan body
(refering to Fig.5 of page 10).
2. Connect the suspension bracket
to fan body. (Fig.13)
(Select the hole by checking -joist size and fix the
screw to the frame hole.)
III
Ⅰ
3. Connect the fan body to the -joist. (Fig.14)
Ⅰ
4. Follow steps 4 to 12 of installation (page 9, page 10) to
complete the installation work.
I
12
4 kinds of
-joist
inches (mm)
Ⅰ
9/16 (14.3)
C1
C2
C3
C4
11/16 (17.5)
31/32 (24.6)
1 17/32 (38.9)
hole
mark
