Controls and displays 03
21
En
Remote control 1 STANDBY/ON
Press to switch the player on or into standby.
2 AUDIO
Press to select the audio channel or language
(see
Switching DVD audio language on
page 39).
3 SUBTITLE
Press to select a subtitle display (see
Switching subtitles on page 39).
4 Number buttons
5 TOP MENU
Press to display the top menu of a DVD disc.
6 ENTER & cursor buttons
Use to navigate on-screen displays and
menus. Press
ENTER to select an option or
execute a command.
7 HOME MENU
Press to display (or exit) the on-screen
display.
8 and
/
Use for reverse slow motion playback, frame
reverse and reverse scanning.
9
Press to start or resume playback.
10
Press to jump to the beginning of the current
chapter or track, then to previous chapters/
tracks.
11
Press to pause playback; press again to
restart.
12 PLAY MODE
Press to display the Play Mode menu. (You
can also get to the Play Mode menu by
pressing
HOME MENU and selecting Play
Mode).
0
1 2 3
4 5 6
7 8 9
CLEAR
ENTER
ANGLE AUDIO
TOP MENU
HOME
MENU
SUBTITLE
PLAY MODE SURROUND ZOOM DISPLAY
MENU
RETURN
ENTER
STANDBY/ON OPEN/CLOSE
/ /
1 14
15
16
17
18
19
20
21
23
2
4
5
6
7
8
10
12
13
3
9
11 22
24
