Quantum 614 Series www.pridemobility.com 37
V I I . C A R E A N D M A I N T E N A N C E
Figure 23. Battery Removal/Installation
REAR SHROUD
REAR BATTERY
FRONT BATTERY
BATTERY
STRAP
PULL POINTS FOR
REAR SHROUD
REMOVAL
DISCONNECT
RELEASE BUTTON
BATTERY WIRING DIAGRAM
