Panasonic KX-PS8100 - Manual (Page 91)

91
Connecting the Printer to a Network
Setting up Windows 95 clients for SMB printing
The following instructions describe printing to a network port using the
Details tab of the Printer Properties dialog. You must specify the option
settings including Server Name in the Service Setup screen, before SMB
printing is enabled.
See “ ■ Service Setup tab” on page 166 .
NOTE:
• The Details tab of the Printer Properties dialog is not available when the
dialog is accessed using File>Print from within applications. This tab
appears only when the Printer Properties dialog is accessed via the
Printers folder.
To set up SMB printing on Windows 95:
1 Click [Start] , select Settings, and click Printers.
2 Click the Panasonic KX-PS8100 printer icon, and select
Properties from the File menu.
3 Click the Details tab in the Properties window and click
[Add\Port] .
4 In the Add Port window, click “Network”, and click
[Browse...] to display your network environment.
