Understanding the Media Path 152
Understanding the Media Path
Understanding the printer’s media path will help you locate media misfeeds.
1 Toner cartridge 8 Fuser unit
2 Laser 9 Main output tray
3 Tray 1 10 Sub output tray
4 Tray 2 11 Duplex (optional)
5 Tray 3 (optional) 12 Face up tray (pagepro 5650EN: standard,
pagepro 4650EN: optional)
6 Tray 4 (optional) 13 Offset tray (optional)
7 Transfer roller
1
2
3
11
12
8
7
13
4
5
6
10
9
