USB Interface
Pin No.
Signal Name Assignment
(Color)
Function
Shell
Shield
Drain Wire
Frame Ground
1
VBUS Red Host
Power
2
D- White
Data
Line(D-)
3 D+
Green
Data
Line(D+)
4 GND
Black
Signal
Ground
Drawer Connector
Pin No.
Signal name
Direction
1 Frame
ground
-
2
Drawer kick-out drive signal 1
Output
3
Drawer open/close signal
Input
4 +24V
-
5
Drawer kick-out drive signal 2
Output
6 Signal
ground
-
* SRP-270 Series Model Listing
Model Name : SRP-27xyz
x Y z
0
5
Ivory
Dark Gray
A
C
D
Basic
Basic
+ Auto cutter
Basic
+ Auto cutter
+ Spool
Blank
S
P
U
RS-232C
RS-485
IEEE-1284
USB
