PLC-EF60A
Professional
3 x 1.4" TFT p-Si (4 : 3), micro lens
2 x 300 W UHP (LMP-80)
5,800
3,000 h (eco mode)/1,500 h (normal mode)
39 dB (eco mode)/42 dB (normal mode)
Delivery without lens
Depending on lens
Depending on lens
1,300 : 1
1,400 x 1,050 (S-XGA+)
30"–500"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: D-Sub15 (RGB), DVI-D (digital/HDCP)
Input 2: 5 x BNC (RGBHV/Video/Y-Pb/Cb-Pr/Cr)
Input 3: 3 x RCA (Video/Y-Pb/Cb-Pr/Cr), Mini DIN 4
(S-Video)
Input 4: freely configurable with optional
interface boards
Input 5: freely configurable with optional
interface boards
Monitor output: D-Sub15
Control Input Jack 1: D-Sub9 (RS232)
Control Input Jack 2: USB type B (Mouse
Control) Control Input Jack 3: 3.5 mm Stereo
Jack (cable remote control)
Control output: D-Sub9 (RS232)
Others: USB type A (USB-Key)
–
vertical +/–40°, horizontal +/–30°
1 : 1 vertical (applies to LNS-W03/W07)2.5 : 1 to 1
: 2.5 vertical (applies to LNS-W05)10 : 0 to 0 : 10
vertical (applies to all other lenses)1 : 1 horizontal
(applies to LNS-W03/W05/W07)2 : 3 to 3 : 2
horizontal (applies to all other lenses)
720 W (eco mode)/900 W (normal mode)/ 13 W
(stand-by mode)/100–240 V
3 years,
518 x 252 x 606 mm
24.7 kg
Wireless remote control, batteries, user manual,
power cable, D-Sub15 cable, software for Real
Colour Manager Pro, 2 lens adapters
6 optional adapter boards: DVI-I Board (POA-
MD18DVI),D-Sub15 Board (POA-MD04VGA),5
BNC Board (POA-MD16VD1),HD-SD-SDI Board
(POA-MD17SDID),Network Board (POA-
MD19NET),Warp & Blending Board (POA-
MD21WARP)
13 interchangeable lenses
PLV-WF20
Professional
3 x 1.2" TFT p-Si (17 : 10)
2 x 330 W NSH (LMP-104)
6,000
3,000 h (eco mode)/2,000 h (normal mode)
47 dB (eco mode)/50 dB (normal mode)
Delivery without lens
Depending on lens
Depending on lens
2,000 : 1
1,366 x 800 (W-XGA)
30"–400"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: D-Sub15 (RGB), DVI-D (digital/HDCP)
Input 2: Mini DIN 4 (S-Video), 5 x BNC
(RGBHV/Video/Y-Pb/Cb-Pr/Cr)
Input 3: freely configurable with optional
interface boards
Input 4: freely configurable with optional
interface boards
Control Input Jack 1: D-Sub9 (RS232)
Control Input Jack 2: 3.5 mm Stereo Jack (cable
remote control)
Control output: D-Sub9 (RS232)
–
vertical +/–40°, horizontal +/–20°
10 : 0 to 0 : 10 vertical (applies to LNS-W05)1 : 1
vertical (applies to LNS-W03/W06/W07)10 : –3 to
–3 : 10 vertical (applies to all other lenses)1 : 1
horizontal (applies to LNS-W03/W07)5 : 3 to 3 : 5
horizontal (applies to all other lenses)
680 W (eco mode)/950 W (normal mode)/
18 W (stand-by mode)/100–240 V
3 years
530 x 267.5 x 757 mm
27.6 kg
IR remote control, batteries, user manual, power
cable, D-Sub15 cable, PIN code label, software
for Real Colour Manager Pro, 3 light-block sheets,
2 lens adapters
8 optional adapter boards:DVI-I Board (POA-
MD18DVI),D-Sub15 Board (POA-
MD04VGA),DVI/D-Sub15 Board (POA-MD23ADI),5
BNC Board (POA-MD16VD1),5 BNC Board (POA-
MD25VD3),HD-SD-SDI Board (POA-
MD17SDID),Network Board (POA-MD13NET2),HD
DATA WIRELESS Receiver Board (POA-
MD26HDWL)
12 interchangeable lenses
PLC-XP100L
Professional
3 x 1.3" TFT p-Si (4 : 3), micro lens
330 W NSH (LMP-108)
6,500
3,000 h (eco mode)/2,000 h (normal mode)
32 dB (eco mode)/40 dB (normal mode)
Delivery without lens
Depending on lens
Depending on lens
2,000 : 1
1,024 x 768 (XGA)
31"–400"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: DVI-D (digital/HDCP)
Input 2: D-Sub15 (RGB/SCART-RGB) or Monitor
Out
Input 3: 5 x BNC (RGBHV/Video/Y-Pb/Cb-Pr/Cr)
Input 4: 3 x RCA (Video/Y-Pb/Cb-Pr/Cr)
Input 5: Mini DIN 4 (S-Video)
Monitor output: D-Sub15
Control Input Jack 1: D-Sub9 (RS232)
Control Input Jack 2: USB type B (Mouse
Control)
Control Input Jack 3: 3.5 mm Stereo Jack (cable
remote control)
–
vertical +/–40°, horizontal +/–20°
10 : 0 to 1 : 1 vertical (applies to LNS-
S31/W31A/T31A/T32)1 : 1 vertical (applies to LNS-
W32)2 : 3 to 3 : 2 horizontal (applies to
LNS-S31/W31A/T31A/T32)1 : 1 horizontal (applies
to LNS-W32)
392 W (eco mode)/490 W (normal mode)/21 W
(stand-by mode)/100–240 V
3 years
370 x 187 x 440 mm
11.7 kg
IR remote control with mouse function, batteries,
user manual, power cable, USB cable, D-Sub15
cable, PIN code label, light-block sheet, lens
adapter
PJ Net Organizer Plus II with video camera (POA-
PN03C)
6 interchangeable lenses
PDG-DHT100L
Professional
1 x 0.95 DMD chip (16 : 9)
2 x 330 W UHP (LMP-130)
6,500
2,500 h (eco mode)/2,000 h (normal mode)
36 dB (eco mode)
Delivery without lens
Depending on lens
Depending on lens
7,500 : 1
1,920 x 1,080 (HDTV 1,080p))
50"–600"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: D-Sub15 (RGB), HDMI (HDCP),
DVI-D (digital/HDCP)
Input 2: Mini DIN 4 (S-Video), 5 x BNC
(RGBHV/Composite/Y-Pb/Cb-Pr/Cr)
Input 3: freely configurable with optional
interface boards
Input 4: POA-MD13NET2 (RJ45(LAN)/D-
Sub9)
Monitor output: D-Sub15
Control Input Jack 1: Mini DIN 8 (RS232)
Control Input Jack 2: 3.5 mm Stereo Jack
(cable remote control)
Control Input Jack 3: USB type B
–
vertical +/–30°, horizontal +/–30°
1 : 1 vertical (applies to LNS-W52)6.65 : -1
to -1 : 6.65 vertical (applies to LNS-
W51/W50/S50/T50/T51)1 : 1 horizontal
(applies to LNS-W52)10.7 : 1 to 1 : 10.7
horizontal (applies to LNS-
W51/W50/S50/T50/T51)
923 W (normal mode)/28 W (stand-by
mode)/100–240 V
3 years
400 x 242.5 x 522.5 mm
19 kg
IR/cable remote control, batteries, user
manual, power cable, D-Sub15 cable, PIN
code label, software for Real Colour
Manager Pro
HD wireless transmitter (POA-HDTM01),7
optional adapter boards: DVI-I Board
(POA-MD18DVI), 5 BNC Board (POA-
MD16VD1), HD-SD-SDI Board (POA-
MD17SDID), Network Board
(POA-MD13NET2), DVI/D-Sub15 Board
(POA-MD23ADI), 5 BNC Board (POA-
MD25VD3), HD DATA WIRELESS
Receiver Board (POA-MD26HDWL)
6 interchangeable lenses
PLC-XP200L
Professional
3 x 1.3" TFT p-Si (4 : 3), micro lens, 1 x
Color Control Device, QuaDrive®
330 W NSH (LMP-124)
7,000
3,000 h (eco mode)/2,000 h (normal
mode)
35 dB (eco mode)/39 dB (normal mode)
Delivery without lens
Depending on lens
Depending on lens
2,200 : 1
1,024 x 768 (XGA)
31"–400"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: DVI-D (digital/HDCP)
Input 2: D-Sub15 (RGB/SCART-RGB) or
Monitor Out
Input 3: 5 x BNC (RGBHV/Composite/Y-
Pb/Cb-Pr/Cr)
Input 4: 3 x RCA (Video/Y-Pb/Cb-Pr/Cr)
Input 5: Mini DIN 4 (S-Video)
Audio: 3.5 mm Stereo Jack
Audio output: 3.5 mm Stereo Jack
Monitor output: D-Sub15
Control Input Jack 1: D-Sub9 (RS232)
Control Input Jack 2: 3.5 mm Stereo Jack
(cable remote control)
Control Input Jack 3: USB type B
–
vertical +/–40°, horizontal +/–20°
10 : 0 to 1 : 1 vertical (applies to LNS-
S31/W31A/T31A/T32)1 : 1 vertical (applies
to LNS-W32)2 : 3 to 3 : 2 horizontal
(applies to LNS-S31/W31A/T31A/T32)1 : 1
horizontal (applies to LNS-W32)
377 W (eco mode)/499 W (normal mode)/
24.5 W (stand-by mode)/100–240 V
3 years
370 x 187 x 440 mm
11.4 kg
IR remote control with mouse function,
batteries, user manual, power cable, USB
cable, D-Sub15 cable, PIN code label,
light-block sheet, lens adapter
PJ Net Organizer Plus II with video
camera (POA-PN03C)
6 interchangeable lenses
PLV-HD2000E
Professional
3 x 1.64" TFT p-Si (17: 9), micro lens
4 x 300 W UHP (LMP-100)
7,000
2,000 h (normal mode)
51 dB (normal mode)
Delivery without lens
Depending on lens
Depending on lens
1,000 : 1
2,048 x 1,080 (2K)
40"–600"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: Dual link SDI
Input 2: 5 x BNC (R,G,B,H,V/Y,Pb/Cb,Pr/Cr)
Input 3: DVI-I (digital/HDCP/analog)
Input 4: freely configurable with optional
interface boards
Audio: 2 x RCA (R/L mono)
Control Input Jack 1: D-Sub9 (RS232)
Control Input Jack 2: USB type B (mouse
control)
Control Input Jack 3: 3.5 mm Stereo Jack
(cable remote control)
Control Output: D-Sub9 (RS232)
–
–
8 : –1 to –1 : 8 vertical (applies to LNS-
S02Z)8 : 1 to 1 : 8 vertical (applies to LNS-
W06)1 : 1 vertical (applies to LNS-W03)10
: 0 to 0 : 10 vertical (applies to all other
lenses)1 : 1 horizontal (applies to LNS-
W03/W04/W06)2 : 3 to 3 : 2 horizontal
(applies to all other lenses)
1,700 W (normal mode)/20 W (stand-by
mode)/ 200–240 V
3 years
581 x 252 x 783 mm
37.2 kg
IR/cable remote control, batteries, user
manual, power cable, software for Real
Colour Manager Pro
4 optional adapter boards:DVI-I Board
(POA-MD18DVI),5 BNC Board (POA-
MD16VD1),Y/C Board (POA-
MD03VD2A),Network Board
(POA-MD13NET2)
11 interchangeable lenses
Model
Category
Panel
Lamp
Brightness ANSI lumens
Average Lamp Life
Fan Noise
Standard Lens
Throw Distance Ratio
Throw Distance (Standard Lens)
Contrast Ratio
Resolution in pixels
Image size min.–max. (diagonal)
Uniformity
Colour Systems
Connections
Audio Function
Keystone Correction
Lens-Shift / U / D / Ratio
Power Consumption/Voltage
Warranty
Dimensions (W x H x D)
Weight
Standard Accessories
Optional Accessories
Lenses
Professional
12 13
PLC-XF71
Professional
3 x 1.8" TFT p-Si (4 : 3)
2 x 330 W NSH (LMP-128)
10,000
3,000 h (eco mode)/2,000 h (normal
mode)
45 dB (eco mode)/46 dB (normal mode)
Delivery without lens
Depending on lens
Depending on lens
3,000 : 1
1,024 x 768 (XGA)
40"–600"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: D-Sub15 (RGB), DVI-D
(digital/HDCP) Input 2: Mini DIN 4 (S-
Video), 5 x BNC (RGBHV/Video/Y-Pb/Cb-
Pr/Cr)
Input 3: freely configurable with optional
interface boards
Input 4: freely configurable with optional
interface boards
Control Input Jack 1: Mini DIN 8 (RS232)
Control Input Jack 2: 3.5 mm Stereo Jack
(cable remote control)
Control Input Jack 3: USB type B
–
vertical +/–40°, horizontal +/–20°
10 : 0 to 0 : 10 vertical (applies to LNS-
S02Z)1 : 1 vertical (applies to LNS-W03)1 :
8 to 8 : 1 vertical (applies to all other
lenses)1 : 1 horizontal (applies to LNS-
W03/W04/W06)2 : 3 to 2 : 3 horizontal
(applies to all other lenses)
780 W (eco mode)/950 W (normal
mode)/17 W (stand-by mode)/100–240 V
3 years
530 x 267.5 x 757 mm
27.6 kg
IR/cable remote control, batteries, user
manual, power cable, D-Sub15 cable, PIN
code label, software for Real Colour
Manager Pro, 2 light-block sheet, 2 lens
adapters
8 optional adapter boards:DVI-I Board
(POA-MD18DVI), 5 BNC Board (POA-
MD16VD1), HD-SD-SDI Board (POA-
MD17SDID), Network Board
(POA-MD13NET2), Warp- & Blending
Board (POA-MD21WARP), DVI/D-Sub15
Board (POA-MD23ADI),5 BNC Board
(POA-MD25VD3), HD DATA WIRELESS
Receiver Board (POA-MD26HDWL)
10 interchangeable lenses
PLC-XF47
Professional
3 x 1.8" TFT p-Si (4 : 3)
4 x 330 W NSH (LMP-109)
15,000
3,000 h (eco mode)/2,000 h (normal mode)
51 dB (normal mode)
Delivery without lens
Depending on lens
Depending on lens
2,000 : 1
1,024 x 768 (XGA)
40"–600"
90 %
PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Input 1: D-Sub15 (RGB), DVI-D
(digital/HDCP) Input 2: Mini DIN 4 (S-
Video), 5 x BNC (RGBHVComposite/Y-
Pb/Cb-Pr/Cr)
Input 3: freely configurable with optional
interface boards
Input 4: freely configurable with optional
interface boards
Control Input Jack 1: D-Sub9 (RS232)
Control Input Jack 2: USB type B (Mouse
Control)
Control Input Jack 3: 3.5 mm Stereo Jack
(cable remote control)
Control output: D-Sub9 (RS232)
–
vertical +/–40°, horizontal +/–20°
10 : 0 to 0 : 10 vertical (applies to LNS-
S02Z)1 : 1 vertical (applies to LNS-W03)1 : 8
to 8 : 1 vertical (applies to all other lenses)1
: 1 horizontal (applies to LNS-
W03/W04/W06)2 : 3 to 3 : 2 horizontal
(applies to all other lenses)
1,550 W (eco mode)/1,700 W (normal
mode)/20 W (stand-by mode)/200–240 V
3 years
581 x 252 x 816 mm
36.5 kg
IR/cable remote control, batteries, user
manual, power cable, D-Sub15 cable, PIN
code label, software for Real Colour
Manager Pro, 3 light-block sheet, 2 lens
adapter
8 optional adapter boards:DVI-I Board
(POA-MD18DVI),D-Sub15 Board (POA-
MD04VGA), DVI/D-Sub15 Board (POA-
MD23ADI),5 BNC Board
(POA-MD25VD3),HD-SD-SDI Board (POA-
MD17SDID),Network Board (POA-
MD13NET2),Warp & Blending Board
(POA-MD21WARP)HD DATA WIRELESS
Receiver Board (POA-MD26HDWL)
11 interchangeable lenses
NEW NEW
