Glossary
360° installation | The projector can be installed
with its own axis, allowing distortion-free
projections at all levels. This is particularly
suitable for situations where flexibility is required,
for example in the case of digital signage and
events.
3LCD | The light emitted from the lamp is
separated into the three basic colours of red,
green and blue. Each of these colours is passed
through its own LCD panel. The light and image
information is then recombined using a dichroic
prism to give realistic colour and shape to the
projected image. The light yield from 3LCD is
always optimal, because the projector is
constantly projecting all three primary colours
onto the screen.
ANSI lumens | Image brightness from a
projector is measured in ANSI lumens. The
brighter a projector, the wider its range of
possible uses in terms of ambient light and
screen size. In accordance with specific
regulations, 9 areas on screen are measured in
the image projected on-screen. The average of
the focus points multiplied by the image surface
gives the lumen reading (Lumen = Lux x m2).
Audio function | Many SANYO projectors have
integrated speakers that can reproduce audio
signals, i.e. sound. The powerful 7 watt speakers
are an innovation in this area. These are
integrated into the multimedia projectors
belonging to the XC series. They are particularly
suitable for use in training and conference rooms.
Auto Lamp Selection System (ALSS) | Projectors
with an integrated lamp change function
guarantee a high level of operating safety,
because a replacement lamp is integrated in the
unit. The replacement is used automatically if
necessary, so that a presentation can be
continued. This greatly reduces the maintenance
frequency for a projector.
Automatic air filter replacement | To ensure
optimal cooling inside the projector, the air filter
must be cleaned or replaced regularly. The
integrated filter cartridge automatically changes
the filter once the built in sensor signals that a
replacement is necessary. A cartridge containing
10 filters allows maintenance-free continuous
operation up to 30,000 hours depending on the
device.
Automatic lens cover | Most home cinema
projectors have an integrated lens cover to
protect the lens from dust. When the projector
shuts down or enters standby mode, the lens
cover closes automatically.
Automatic setup | The automatic setup allows
the projector to promptly register the connected
device. Using the signal detection, keystone
correction and auto PC adjustment, the projector
adapts to the properties of the connected device
and ensures that the presentation is ready to
start in a matter of seconds.
Connector socket | Different connector sockets
are available for the different signal types:
Contrast ratio | This is the ratio between the
maximum (white) and minimum (black)
luminance that can be displayed by a projector.
The higher the ratio, the better, i.e. the image
displays black more effectively.
Digital zoom | The digital zoom function allows
the user to select and enlarge a section of the
presentation.
Direct Power On/Off | These functions let you
switch the projector on and off without delay.
Direct Power On: The projector powers up the
moment it is plugged in. This is very convenient
and it provides the user with great flexibility.
Direct Power Off: With this function, the
projector can be unplugged while it is in
operation. This lets you transport it quickly
without having to wait for it to cool down and
without damaging the lamp.
Signal type Connector socket
D-Sub15 VGA
RCA Composite, Component
DVI/HDMI Digital signals
BNC RGB, Video, S-Video
Mini Din 4 S-Video
Mini Din 8 Service input (RS232 control)
21
Optional Accessories
SST-Bracket-WH
Wall bracket for projectors
PLC-XL50 and PLC-XL51
Mount system with a flexible
fastening rail for 60–80 inch
image sizes
Horizontal position can easily
be changed by up to 25 cm
3 regulating screws for easy
adjustment of the vertical position
Colour: white
Dimensions (W x H x D):
250 x 680 x 320 mm
Weight: 9 kg
POA-PN40
PJ Net Organiser
Network manager
Projector status control
and function control
Network standard (LAN):
IEEE802.3 (10BASE-T)/
IEEE802.3u (100BASE-TX)
Data transfer speed (LAN):
10 Mbps/100 Mbps
(half duplex/full duplex)
LAN interface: 8 modular (RJ45)
Suitable for: PLV-80L
POA-CW01
6-segment colour wheel
Large colour space for higher
colour and image quality
Includes cyan, yellow
and magenta in addition to
the primary colours red, green
and blue
Suitable for: PDG-DXT10L,
PDG-DWT50L
POA-PN03C
PJ Net Organiser Plus
Network manager
Real-time data transfer
Mobile camera as a control
function
Projector status control
and function control
Network standard (LAN):
IEEE802.3 (10BASE-T) /
EEE802.3u (100BASE-TX)
Suitable for: PLC-XT21,
PLC-XT35L, PLC-ET30L,
PLC-XP100L, PLC-XP200L,
PLC-XTC50L
POA-HDTM01
HD wireless transmitter
for wireless data transfer
Only compatible in combination
with the optional interface board
POA-MD26HDWL
Maximum range: 30 meter
Data transfer rate: max. 1.5 GB/s
Dimensions (W x H x D):
270 x 50 x 220 mm
Weight: 1.3 kg
Suitable for PLC-XF47, PLC-XF71,
PLV-WF20, PDG-DHT100L
ST-Boom-WH
Weight: 10kg
Colour: White
Optional Active Speakers
(Active Speakers-WH)
Zoom: 1000mm
SANYOBOSS1
Universal Ball joint
for 360 degree swivel
30 degree tilt
Fits 50mm ceiling poles
11mm wide security cable
Dimensions: 410 x 270 x 3mm
Weight 2.5kg
20
POA-RCKIT04
Remote control presentation
Mouse function
Power supply: 2 batteries,
type AAA or LR03 (supplied)
Operating range: 5 m or +/–30°
Dimensions (W x H x D):
51.5 x 23.2 x 123.0 mm
Suitable for: PLC-XL50,
PLC-XW57, PLC-XW60,
PLC-XW65, PLC-XU75A,
PLC-XU78, PLC-XU105
