X3.60 16 Volts DC 14.4 Volts DC 12 Volts DC
Impedance Load Measurement
1 Ohm
2 Ohm
4 Ohm
RMS Wattage
RMS AC Volts
RMS Wattage
RMS AC Volts
RMS Wattage
RMS AC Volts
1% THD 1% THD 1% THD 5% THD 5% THD 5% THD 10% THD 10% THD 10% THD
2860 2940 3180 2780 2880 3115 2560 2635 2840
53.4 54.2 56.3 52.7 53.6 55.8 50.5 51.3 53.3
2070 2130 2300 1920 1988 2150 1344 1380 1490
64.3 65.3 67.8 61.9 63 65.6 51.8 52.5 54.5
1086 1120 1200 1050 1085 1178 898 925 998
65.9 66.9 69.3 64.8 65.8 68.6 59.9 60.8 63.1
FEATURES
Specifications
* "maximum" current consumption reading was extracted at the impedance specified and at
a source voltage of 14.4V DC
4000Watts
350<@80Hz(+/- 5Hz)
15Hz ~150Hz
0.5 ~ 10.0 (volts)
24dB / octave
18dB
50Hz ~ 150Hz
0 ~ 180 deg.
0 ~ 18dB
11 ~ 16V DC
249 amperes DC *
21" x 11.5" x 2.5"
13.5V DC & 14.4V DC Max Power
Damping factor
Operating frequency(band-width)
Input Sensitivity
Low-Pass crossover slope attenuation factor
Subsonic(cut/increase) range factor (15Hz ~ 40Hz)
Continuously variable low-pass control(range)
Continuously variable phase control(range)
Continuously variable bass boost control(range)
Source voltage (Automobile battery)(range)
Maximum DC current 1 Ohm, 1% THD +n
Dimensions(L x W x H)
Test voltage
Platinum RCA connectors
Strap-able; Slave-master relationship
Source voltage is limited to 11V~16V.
If source voltage beyond this limit is applied to the Amplifier, the warranty will be voided.
X3.60
3
FE
ATURES & SPECIFIC
ATIONS
4000 Watt 2-second Burp Power at 16V and 10%
