Class 8839 Econoflex™ AC Drives
Dimensions and Weights
199
09/2003
©
2000–2003 Schneider Electric All Rights Reserved
DIMENSIONS AND WEIGHTS FOR TYPE 1 AND TYPE 12K ENCLOSURES
Ø
1.00
(25.40)
Lifting
Hole
B
A
Conduit Entry - Top View
K
L
Ш
0.37
(9.40)
Ш
0.88
(22.35)
D
E
1.85
(47.00)
C
F
Conduit Entry - Bottom View
Vents in Type 1 Only
Vents in Type 1
Only
K
L
Ø
0.37
(9.40)
13.56
(344.22)
12.04
(305.82)
3.25
(82.55)
NOTE: Provide at least 3 in.
(77 mm) of mounting
clearance on each side of
the drive controller and 6 in.
(152 mm) at the top and
bottom of the drive
controller.
Dimensions: in. (mm)
Mounting Information for 1 to 20 HP 460 Vac and 1 to 10 HP 208/230 Vac Controllers
Knockout Dimensions
460 Vac
208/230 Vac
K
L
1 to 7.5 HP
1 to 5 HP
For 1/2" conduit
For 1/2" conduit
10 to 20 HP
7.5 to 10 HP
For 1/2", 3/4", and 1" conduit
For 1/2", 3/4", and 1" conduit
HP
HP
Weight
Enclosure Dimensions
A
B
C
D
E
F
460
Vac
208/230
Vac
lb
kg
in
mm
in
mm
in
mm
in
mm
in
mm
in
mm
1 to 7.5
1 to 5
87
39.5
32.00
812.8
35.00
889.00
33.75
857.25
14.25
361.95
12.29
312.17
14.76
374.90
10 to 20
7.5 to 10
126
57.2
38.00
965.2
41.0
1041.40
39.75
1009.65
19.49
495.05
17.53
445.26
20.52
521.21
