Description
The SCOTCH meshOrderSave routine saves the contents of the SCOTCH
Ordering
structure pointed to by ordeptr to stream stream, in the Scotch
ordering format (see section 5.6).
Return values
SCOTCH meshOrderSave returns 0 if the ordering structure has been success-
fully written to stream, and 1 else.
7.9.5 SCOTCH meshOrderSaveMap
Synopsis
int SCOTCH meshOrderSaveMap (const SCOTCH Mesh * meshptr,
const SCOTCH Ordering * ordeptr,
FILE * stream)
scotchfmeshordersavemap (doubleprecision (*) meshdat,
doubleprecision (*) ordedat,
integer fildes,
integer ierr)
Description
The SCOTCH meshOrderSaveMap routine saves the block partitioning data as-
sociated with the SCOTCH Ordering structure pointed to by ordeptr to stream
stream
, in the Scotch mapping format (see section 5.5). A target domain
number is associated with every block, such that all node vertices belonging
to the same block are shown as belonging to the same target vertex.
This mapping file can then be used by the gout program (see section 6.3.12)
to produce pictures showing the different separators and blocks. Since gout
only takes graphs as input, the mesh has to be converted into a graph by
means of the gmk msh program (see section 6.3.8).
Return values
SCOTCH meshOrderSaveMap returns 0 if the ordering structure has been suc-
cessfully written to stream, and 1 else.
7.9.6 SCOTCH meshOrderSaveTree
Synopsis
int SCOTCH meshOrderSaveTree (const SCOTCH Mesh * meshptr,
const SCOTCH Ordering * ordeptr,
FILE * stream)
scotchfmeshordersavetree (doubleprecision (*) meshdat,
doubleprecision (*) ordedat,
integer fildes,
integer ierr)
