32
4
If the scanned image is incorrectly positioned, refer to the check list shown below.
CHECK1 Have you placed the original straight?
Place the original straight on the original table.
Reference: Refer to "ORIGINAL PLACEMENT" in the
Operation Manual for the detail on how to
set the original.
CHECK2 Have you set the original correctly on the
original table?
Place the original on the original table in the
direction as shown in the illustration below.
CHECK3 Have you set the original correctly on the
RSPF/SPF?
To scan from the RSPF/SPF, align the guide to the
original as shown in the illustration below.
Align the center of the original with ( ) mark.
Align the guide to the original.
The Scanned Image is Incorrectly Positioned
