MOON W5.3 Stereo Power Amplifier
Specifications
Configuration ......................................................... Stereo
Power Supply Transformer ...................................... 1.0kVA
Power Supply Capacitance ...................................... 115,000µF
Class Of Operation ................................................. A/AB
Design .................................................................... Balanced Differential to output stage
Input Impedance ................................................... 47,500
Ω
Input Sensitivity ..................................................... 1000mV
Output Device Type ................................................ Bipolars - 8 per channel
Output Power at 8
Ω ............................................... 150 Watts per channel
Output Power at 4 Ω .............................................. 300 Watts per channel
Output Power – Bridged Mono at 8 Ω ....................... 600 Watts
Frequency Response .............................................. 10Hz - 125kHz +0/-3dB
Output Impedance ................................................. 0.01
Ω
Damping Factor (static) ......................................... 800
Gain ...................................................................... 31dB
Signal-to-noise Ratio .............................................. > 100dB @ full power
Maximum Output Voltage ....................................... 40 Volts
Slew Rate .............................................................. 42V/µs
Maximum Current – Peak ........................................ 38 amperes
Maximum Current – Continuous .............................. 20 amperes
Crosstalk @ 1kHz ................................................... -100dB
Intermodulation Distortion ...................................... Unmeasureable
THD (20Hz - 20kHz @ 1 watt) ................................ < 0.02 %
THD (20Hz - 20kHz @ 150 watts) .......................... < 0.05 %
Power Consumption @ idle ..................................... 45 Watts
AC Power Requirements ......................................... 120V / 60Hz or 240V / 50Hz
Shipping Weight ..................................................... 50 lbs / 22 Kgs
Dimensions (W x H x D, inches) .............................. 17 x 7.5 x 17
Balanced Pin Assignment: Pin 1................................ Ground
Pin 2................................ Positive
Pin 3 .............................. Negative
12 Volt Trigger: Logic ............................... Direct (0V off, 12V on)
Jack................................. 3.5mm microphone jack
Input Impedance ............. 1k Ω
Current Consumption........ 12mA
Fuse Replacement: For the 120V version use a 6A fast blow (3AG size).
For the 230V version use a 3A fast blow (3AG size).
____________________________________________________________________________________
