8
Momentus 5400.3 SATA Blade Server Product Manual, Rev. E
• Idle mode power
Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in
a random track location.
• Standby mode
During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/
write electronics are in power-down model
*During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and
power to operational levels.
Figure 1. Typical +5V startup and operation current profile
Table 3:
DC power
Power dissipation
+5V input average (25° C)
Spinup
1.0 A
Seek
2.0 watts
Read
1.9 watts
Write
1.8 watts
Idle, performance mode*
1.4 watts
Idle, active*
0.75 watts
Idle, low power mode*
0.6 watts
Standby
0.2 watts
Sleep
0.2 watts
