Momentus 5400.3 SATA Blade Server Product Manual, Rev. E 5
*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment
and formatting.
**Typical notebooks will pull power to the drive when entering S3 and S4; while in the S3 and S4 states, drive sleep and drive standby modes
will not contribute to battery power consumption.
***During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and
power to operational levels.
2.2 Formatted capacity
*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment
and formatting.
2.2.1 LBA mode
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1,
where n is the number of guaranteed sectors as defined above.
See Section 4.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48-
bit addressing support of drives with capacities over 137 Gbytes.
2.3 Default logical geometry
LBA mode
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1,
where n is the number of guaranteed sectors as defined above.
Warranty 5 years on distribution units.
To determine the warranty for a specific drive, use a web browser to access the following web
page:
www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. You will be asked to provide the drive
serial number, model number (or part number) and country of purchase. The system will display
the warranty information for your drive.
Supports Hotplug operation per
Serial ATA Revision 2.5 specifica-
tion Yes (requires COMPRESET from host after a hotplug event)
Model Formatted capacity* Guaranteed sectors Bytes per sector
ST9160821SB 160 Gbytes 312,581,808 512
ST9120822SB 120 Gbytes 234,441,648 512
ST9100828SB 100 Gbytes 195,371,568 512
ST980815SB 80 Gbytes 156,301,488 512
ST960815SB 60 Gbytes 117,210,240 512
ST9402116SB 40 Gbytes 78,140,160 512
Cylinders Read/write heads Sectors per track
16,383 16 63
Table 1: Drive specifications
Drive specification ST9160821SB ST9120822SB ST9100828SB ST980815SB ST960815SB ST9402116SB
