Sundance Spas 680 - Manual (Page 27)

Page 21
680 SERIES
8.0 Control Functions
8.1 Control Panel
A. LED Display: Can display current
water temperature (default display),
water temperature set point, selected
filtration/heating mode, and error
messages.
B. Heat Indicator: Lit when heater is
on.
C. Warmer (
) Button: Increases water temperature set point.
D. Cooler ( ) Button: Decreases water temperature set point.
E. Jets 1 Button: Turns jets pump #1 on and off. Press once for low
speed; press a second time for high speed; press a third time to turn
pump off.
F. Jets 2 Button (Hartford and Hawthorne Models): Turns jets pump
#2 on and off. Press once for high speed; press a second time to turn
pump off.
G. Light Button:
• Denali and Tacoma Models: Turns underwater light on in random
mode or in one of six solid colors. Refer to Section 9.3 (page 24)
for details.
• Burlington, Hartford and Hawthorne Models with standard
Incandescent light system: Turns underwater light on and off.
Refer to Section 9.4 (page 24) for details.
• Burlington, Hartford and Hawthorne Models with optional LED
lighting system: Turns underwater light and top rim accent lights
on in one of three random modes or one of seven solid colors.
Refer to Section 9.5 (page 24) for details.
Operation Details
• Temperature Adjustment: 65 to 104°F (18 to 40°C). Factory
default setting is 100°F (38°C).
• All lighting systems run for 1 hour then shut off.
• Jets 1/Jets 2 Button Operation: Jets run for 20 minutes after
activated, then turn off automatically to conserve energy. Simply
press either jets button to continue operation for an additional 20
minutes.
A
B
C D
E F G
2 Pump Panel Shown
