JVC GD V502U - Manual (Page 12)

12
PC IN
AUDIO
SLOT1
S VIDEO IN
VIDEO IN VD HD P R /C R /R P B /C B /B Y/G
COMPONENT/RGB IN AV
SLOT2 SLOT3
R AUDIO L
IN
R AUDIO L VIDEO OUT
VIDEO
OUT
VIDEO IN
S VIDEO
OUT AUDIO
OUT
R L
AUDIO
OUT
Y, P B , P R ,
OUT
R R
P B
Y
L
R
COMPONENT VIDEO OUT
VIDEO IN VD HD P R /C R /R P B /C B /B Y/G
COMPONENT/RGB IN AV
R AUDIO L VIDEO OUT
Connections
DVD
Computer RGB Camcorder
or
Notes:
(1) Change the “Component/RGB-in” setting in the “Setup” menu to “Component”. (see page 33)
(2) Additional equipment, cables and adapter plugs shown are not supplied with this set.
Notes:
(1) Change the “Component/RGB-in” setting in the “Setup” menu to “RGB”. (see page 33)
(2) Additional equipment, cables and adapter plugs shown are not supplied with this set.
S VIDEO VCR
CAMCORDER
VCR
MONITOR
RCA-BNC
adapter
plug
Example of input signal source
Example of input signal source
Digital TV-SET-TOP-BOX
(DTV-STB)
AV & COMPONENT Connection
RGB signal (R, G, B, HD, VD)
