Page 50
J-400 Series
11.0 Operating Instructions
11.1 J-1000™ Control Panel
Your Jacuzzi spa is equipped with a J-1000™ control panel, massage
selectors, and air control knobs located on the top rim of the spa (pages
22-33). These controls let you operate many of the special functions of
your Jacuzzi spa. When you press button B from the Main Menu, you will
enter the Jets pump submenu (Figure A).
D
C
B
A
JETS
Jet 1
Jet 2
OFF
OFF
= Jets Pump 1 icon
= Jets Pump 2 icon
= button a: Turns Jets pump 1 on and off.
= button C: Turns Jets pump 2 on and off.
= button D: Press this button to return to the Main Menu.
11.2 activate Jets Pump
From the Main Menu (page 35), press button B to enter the Jets Pump
Submenu. The LCD screen will display the Jets Pump Submenu
(Figure A). From this menu you can control both pumps in the following
sequence:
1. Press button A to activate pump #1.
2. Press again to turn pump #1 off.
3. Press button C to activate pump #2.
4. Press again to turn pump #2 off.
The pumps will move from an “OFF” state into an ON ( ) state.
Auto Turn Off — Anytime a pump has been manually turned on, it will
automatically turn off after approximately 20 minutes. If at this time you
desire more jet operation you may simply turn the pump(s) back on.
Figure A
a
C
D
JETS ICON
WHEN OFF
JETS ICON
WHEN ON
