Page 16
J-400 Series
7.0 Power requirements
Jacuzzi® spas are designed to provide optimum performance and
flexibility of use when connected to their maximum electrical service.
They are configured at the factory. The most common electrical
connections are listed below:
all north american 60 Hz models only: • These models come set for
50A logic. If you prefer, your qualified technician can perform a logic
modification that allows the spas to operate on a different electrical
service (see table footnotes below).
north american J-460/J-465/J-470/J-480 models (60 Hz)
Voltage: 240 VAC 240 VAC 240 VAC
Max. Current Draw: 23A 36A 45A
Frequency: 60 Hz 60 Hz 60 Hz
Number of Wires: 3 3 3
Circuit Breaker (2-Pole): 30A* 50A** 60A***
*
In 30A configuration, the heater will not operate while either jets
pump is running.
** In 50A configuration, the heater will not operate while both jet
pumps are running. This is the factory setting.
*** In 60A configuration the heater will operate while both jet pumps
are running.
all export 50 Hz models: • These models have two terminals
requiring 2 circuit breakers and only have one logic option available.
export J-460/J-465/J-470/J-480 models (50 Hz)
Main
Terminal Breaker*
Heater
Terminal Breaker**
Voltage: 230 VAC 230 VAC
Max. Current Draw: 16.6A 12A
Wattage 3.8 kW 2.6 kW
Frequency: 50 Hz 50 Hz
Number of Wires: 3 3
*
The main terminal breaker is solely for the pumps, circulation
pump, ozone, stereo option (if installed) and accessories.
** The heater breaker is solely for the heater, to allow the heater to
operate while both jet pumps are running.
note: Two breakers needed see Figure e page 14.
