1. Overview
Headset
[1] Visual indicator
[2] Answer/End button
[3] Volume up/down
[4] Ear hook
[5] Mute button
[6] Microphone
[7] Reset button
[8] Snap-on cover (replaceable) Base unit
[9] Charge cradle
[10] Visual indicator
[11] Clear dial tone switch
[12] AUX port
[13] Telephone port
[14] Handset port
[15] AC power adapter port
[16] Transmit volume
[17] Reset button
[18] Headset switch Cords & adapters
[19] Connection cord
[20] AC power adapter
[21] Dongle
[22] Travel charger
[23] USB cable for travel
charger
Definition of “Tap, double tap and press”:
Tap = Press the button for up to 0.8 sec.
Press = Press a button for longer than 0.8 sec, and release before 1.5 sec. Listen for a tone.
Double tap = Two taps made within 0.5 sec.
