Front Panel
Rear Panel
Remote control
On-screen display
If you press ENTER (OK ) on the remote control when “O.S.D.” is
set to “ON” (
੬
15), you can see the current recorder status on the
screen. To clear the on-screen display, press ENTER (OK ) again.
The indications are not recorded even if the recorder is in the
recording mode.
A Operation mode indicators
B Tape speed SP/LP/EP
C Colour system indicator (
੬
15)
D Tape direction
E Counter display
F Tape remaining time indicator
G Audio mode display (
੬
8)
H Tape position indicator (
੬
8)
I Type of broadcast (
੬
9)
J Current day/month/year
K Clock display
L Channel position number/Aux. indicator (L-1, F-1, S-1 or S-2)
M Cassette loaded mark
Buttons, Connectors and Indicators
PLAY:
FF/REW VARIABLE
SHUTTLE SEARCH:
STILL:
SLOW:
RECORD:
RECORD PAUSE:
AUDIO DUBBING:
AUDIO DUBBING PAUSE:
REVIEW SP
+8
4
0
6
15dB
NORM
Cassette loading slot
Display panel
“Timer”
indicator
B.E.S.T. picture
system display/Audio
level indicator
Mode display
(L-1, F-1, S-1 or S-2)
Channel display/
Clock display
Infrared beam
receiving window
Instant
REVIEW
indicator
Counter display
Pause 9 Play 4
Record 7
S-VIDEO(S-2)/VIDEO/AUDIO
input connectors
A. DUB
Stop/Eject
0
REC LINK indicator
Tape remaining
time indicator
S-VHS
indicator
Symbolic
mode
indicators
1
Advanced
JOG dial
24H
EXPRESS #
REC LINK
Audio mode indicator “Cassette Loaded”
mark
Tape speed
indicators
Programme start time and
stop time indicators
(MONO)
Mains power cord
Lithium battery compartment
Remote PAUSE
Buttons with a small dot on the left side of the name can also be
used to operate your TV (
੬
17).
CABLE/
SAT/DVD TV VCR
number keys
Record 7 7 7 7
Stop 8 8 8 8
Rewind Play 4 4 4 4
Fast Forward
Pause 9
9 9 9
