Your recorder needs to memorise all necessary stations in channel
positions in order to record TV programmes. Auto Channel Set
automatically assigns all receivable stations in your area so that
you can call them up with the PR +/– buttons without going
through any vacant channels.
Auto Channel Set
A
Turn on the recorder
Press 1.
B
Access Main Menu screen
Press MENU.
C
Access Tuner Set screen
Press PUSH JOG rt to place the
pointer next to “TUNER SET”, then press
OK or PUSH JOG e.
D
Select Auto CH Set mode
Press PUSH JOG rt to place the
pointer next to “AUTO CH SET”, then
press OK or PUSH JOG e.
E
Select TV system
Press PUSH JOG rt to place the
pointer next to the appropriate TV
system, then press OK or PUSH JOG e.
● Auto Channel Set will start.
F
Return to normal screen
Press MENU.
NOTE:
If you perform Auto Channel Set when the aerial cable is not
connected properly, “SCAN COMPLETED -NO SIGNAL-” appears
on the screen in step 5. When this happens, make sure of the
aerial connection and press OK; Auto Channel Set will take place
again.
Manual Channel Set
Store channels that were not stored during “Auto Set Up” (
੬
5) or
“Auto Channel Set” (
੬
18).
A
Access Tuner Set screen
Perform steps 1 – 3 of “Auto Channel Set” on page 18.
B
Access Channel list
Press PUSH JOG rt to place the pointer next to “CH EDIT”,
then press OK or PUSH JOG e.
C
Select position
Press PUSH JOG rt to place the pointer next to an open
channel position, then press OK or PUSH JOG e.
D
Select band
Press PUSH JOG rt to place the pointer next to the band of your
choice, then press OK to initiate Manual Channel Set.
E
Set desired station
The screen to the right appears when a
station is detected.
If you do not want to store the detected
station...
Press PUSH JOG rt to place the
pointer next to “CONTINUE”, then press
OK or PUSH JOG e. Channel search will resume.
If you want to store the detected station...
Press PUSH JOG rt to place the pointer next to “STORE”, then
press OK or PUSH JOG e. The Channel List appears again.
● The blueback screen and the TV picture currently being
broadcast appear alternately for 8 seconds each.
● If you want to store another channel, repeat steps 3 – 5.
● When channel search completes for that band, the Band Select
screen appears again. To set channels for other bands, select
another band and start Manual Channel Set again (
੬
step 4
and 5).
Delete a Channel
A
Access Tuner Set screen
Perform steps 1 – 3 of “Auto Channel Set” on page 18.
B
Access Channel list
Press PUSH JOG rt to place the pointer next to “CH EDIT”,
then press OK or PUSH JOG e.
C
Select channel
Press PUSH JOG rt until the channel
you want to delete begins blinking.
D
Delete channel
Press &.
● To re-store it, simply press
PUSH JOG w.
● Repeat steps 3 – 4 as necessary.
E
Return to normal screen
Press MENU.
Swap Channel Positions
Example: To swap CH03 and CH09.
A
Access Tuner Set screen
Perform steps 1 – 3 of “Auto Channel Set” on page 18.
Tuner Setting
Turn on the TV and select the VIDEO channel (or AV mode).
IMPORTANT
Perform the following steps only if auto channel set has not
been set correctly by Auto Set Up function (
੬
5) or if you have
moved to a different area or if a new station starts broadcasting
in your area.
IMPORTANT
● If no sound accompanies the picture or the audio sounds
unnatural on some channels that have been stored by Auto
Channel Set, the TV system setting for those channels may be
incorrect. Select the appropriate TV system for those
channels.
੬
“TV System Selection — When you see the
picture but the audio can’t be heard or sounds unnatural” on
page 19.
● Since your video recorder memorizes all detected stations
even if the reception condition is poor, some of those stored
stations may produce a noisy picture. To delete those stations,
੬
“Delete a Channel” on page 18.
PROGRAMME NAVIGATION
FUNCTION SET
TUNER SET
INITIAL SET
MAIN MENU
[MENU] : EXIT
[R/T]
CH EDIT
AUTO CH SET
TUNER SET
[MENU] : EXIT
[R/T]
B/G
D/K
I
M
TV SYSTEM SELECT
[MENU] : EXIT
[R/T]
CH FRQ SYS CH FRQ SYS
01 150 BG 07 229 BG
02 165 BG 08 237 BG
03 195 BG 09 355 BG
04 205 BG 10 365 BG
05 213 BG 11 374 BG
06 221 BG 12 384 BG
[MENU] : EXIT
[R/T] : EDIT
[R/T] [&] : DELETE
AUTO CH SET
PLEASE WAIT
START FINISH
■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ – – – – – – –
VHF L
VHF H
UHF
BAND SELECT
[MENU] : EXIT
[R/T]
PLEASE WAIT
VHF L 100MHZ
MANUAL CH SET
[MENU] : EXIT
STORE
CONTINUE
[MENU] : EXIT
[R/T]
CH FRQ SYS CH FRQ SYS
01 150 BG 07 229 BG
02 165 BG 08 237 BG
03 195 BG 09 355 BG
04 205 BG 10 365 BG
05 213 BG 11 374 BG
06 221 BG 12 384 BG
[MENU] : EXIT
[R/T] : EDIT
[R/T] [&] : DELETE
CH FRQ SYS CH FRQ SYS
01 – – – – – 07 229 BG
02 165 BG 08 237 BG
03 195 BG 09 355 BG
04 205 BG 10 365 BG
05 213 BG 11 374 BG
06 221 BG 12 384 BG
[MENU] : EXIT
[R/T] [Y] : ADD
