Tandem Trailer Page 17
KEY PART NO. DESCRIPTION QTY.
1 75-2200 Trailer Frame Assembly-XT2200 1
75-2200-L Trailer Frame Assembly-XT2200L 1
75-2200-XL Trailer Frame Assembly-XT2200XL 1
2 75-2020 Plate, Brake Actuator Mount (Optional) 1
3 956-3803 Jack 1
4 75-0074 Hitch Plate Assy, (Prior to Serial #0822225) 1
75-0076 Hitch Plate Assy. (Serial #0822225 & Later) 1
5 851-6311-2Z 5/8-11x2" Machine Bolt Grade 5 (Prior to Serial #0822225) 6
881-1014-2.5Z 1x2-1/2" Machine Bolt Grade 8 (Serial #0822225 & Later) 4
6 815-6311-Z 5/8-11 Nylon Insert Locknut (Prior to Serial #0822225) 6
884-1014-Z 1-14 Top Locknut (Serial #0822225 & Later) 4
7 75-2005 Optional Swivel Hitch (Prior to Serial #0822225) 1
901-3757 Swivel Hitch Assy. (Serial #0822225 & Later) 1
MODEL XT2200, XT2200L & XT2200XL FRAME
SERIAL #0822201 AND LATER
PRIOR TO
SN# 0822225
