MB QUART REF4.50 - Manual (Page 7)

Mono Amplifiers
REF1.800
6
FEATURES:
- 1 Set of RCA inputs
- LEVEL: Variable sensitivity from 0.2V to 5V
- BASS EQ: Adjustable 45Hz bass boost from 0dB to 12dB
- SUBSONIC: Variable from 15Hz to 55Hz
- LOW PASS: Variable from 40Hz to 150Hz
- MASTER OUT: Mono RCA signal to Slave amplifier when linking.
- SLAVE IN: Mono RCA signal in from Master amplifier when linking.
- MODE: Selectable Slave In and Master Out selection when linking amplifiers.
- REMOTE: Connection for dash mount level control.
Interconnect cable checklist:
Connect the inputs to a suitable source, e.g. a head unit with good quality RCA cables.
Control checklist:
Refer to the section “Settings for Best Performance”
Use at least #12 gauge speaker wiring. The amps have dual speaker terminals,
simplifying the hookup of multiple speakers. These amps are mono, 1 channel, amplifiers
Minimum final loudspeaker impedance: 1-Ohm.
which have multiple positive and negative connections for ease of wiring. The 2 positives
are the same internally and the 2 negatives are the same internally.
