Chapter 2 Hardware Installation
2.1 Physical Description
8-Port Front View
16-Port Front View
8-Port Rear View
16-Port Rear View
2.1.1 Front LED
LED Status Operation
Online Red/On
On to indicate that a PC is successfully
connected to the KVM.
Select
Blue/On
On to indicate the selected PC on the local
monitor.
Bank
Bank No./On
Indicates bank number of the device (Useful
for Daisy Chain connection).
2.1.2 Rear Description
y Local Console: This interface is for connecting local monitor,
keyboard and mouse that will be used to control the KVM.
y PC: For connecting 3-in-1 Cable from KVM to PC.
