MicroNet Technology SP218D - Manual (Page 18)

3.5.2 Port Name
The first page shows the current port name, the selected port, and the
operation hint.
Command Description
F1 Go to the Main Menu.
F2
Logouts of the OSD. If
Security is enabled it will
show up the Login window
waiting for username and
password. If Security is
disabled it will show the
Status window.
F3
Previous Menu
Enter
Switch to the selected port
↑/↓
Select the port (press Enter
to switch)
PgUp Previous Bank
PgDn Next Bank
Esc Exit
1 Show ports 01 ~ 08
2 Show ports 09 ~ 16
3 Show ports 17 ~ 24
4 Show ports 25 ~ 32
y The numeric keypad is not supported, while in OSD screen, the arrow
keys, PgUp, PgDn, and Enter keys are supported.
14
