ThinkCore W311/321/341 Hardware User’s Manual

Hardware Connection Description

SD Slot

USB (W341 only)

The ThinkCore W341 includes two USB 2.0 hosts. These hosts can be used for an external flash
disk or hard drive in order to store large amounts of data.

Relay Output (W341 only)

The ThinkCore W341 includes a relay output channel. There is a 3-pin
terminal block for the relay output connection, with pinouts as shown in the
figure.

RELAY

COM

3-5
