ThinkCore W311/321/341 Hardware User’s Manual
Hardware Introduction
Appearance
ThinkCore W311
Ethernet
(10/100BaseTx)
12 to
48 VDC
Wireless LAN
antenna
Serial
console port
Serial Port
(RS-232/422/485)
ThinkCore W321
Ethernet
(10/100BaseTx)
12 to
48 VDC
Wireless LAN
antenna
Internal SD Slot for
Storage Expansion
(remove cover to access)
Serial Port 2
(RS-232/422/485)
Serial Port 1
(RS-232/422/485)
Serial
console port
2-2
