2
Step Size (Quantity) Color Torque
2 M2.5 x 5L(2) Blue 2.5 kgf-cm
5
4
3
6
7
Note: When removing the LCD, take note of the following:
v Be careful not to scratch the LCD bezel when
removing the screw mylars.
v The LCD bezel has several latches. Release
these latches; then remove the LCD bezel. Be
careful not to break these latches.
v Gently push the two LCD latches outward to
remove the LCD bezel.
1260 LED/Inverter board (12.1
″/Hitachi)
v “1020 Battery assembly” on page 138
v “1070 EZ key cover” on page 144
v “1080 Keyboard” on page 144
v “1140 Middle cover” on page 150
v “1150 LCD assembly” on page 152
v “1250 LCD bezel assembly (12.1″/Hitachi)” on page 165
166 ThinkPad i Series 1200/1300 HMM
