33
Technical Data
This cooker is category II2H3+
It is supplied set for group H natural gas. A conversion kit from NG to LP gas is included.
INSTALLER: Please leave these instructions with the User.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening.
Country of Destination: GB/IE
Gas (Rp 1 /
2
at rear right-hand side) Electric
Natural Gas 20mbar 220 - 240V 50Hz
Propane 37mbar
Butane 29mbar
(See appliance data badge for test pressures)
Dimensions
Overall height minimum 915mm maximum 942mm
Overall width 900mm; See ‘Positioning of Cooker’
Overall depth 660mm (600mm excluding handles)
Space for fixing See ‘Positioning of Cooker’
Minimum space above hotplate 800mm
Ratings
Natural Gas L.P. Gas
Hotplate Input Injector Bypass Input Injector Bypass
Centre Burner 5.0kW 165 96 5kW (357g/h) 107 57
Large Burners 3.0kW 120 54 3.0kW (214g/h) 82 40
Right hand front Burner 1.7kW 95 39 1.7kW (121g/h) 64 32
Gas burner inputs based on Gross Calorific Value
Grill 2.3kW
Ovens
Main Oven Tall Oven
Multifunction Forced air convection
3.7 kW 2.5 kW
Energy efficiency class :
on a scale of A (more efficient) to G (less efficient)
B B
Energy consumption based on standard load 0.85kWh 0.95kWh
Usable volume (litres) 62 53
Size Medium Medium
Time to cook standard load 41 minutes 49 minutes
Baking area 1400cm 2 790cm 2
Maximum total electrical load at 230V: 7.4kW approximate total including, oven fan, etc.
