Genesis I.C.E. 12t - Manual (Page 17)

17 17 17 17
~ДлздмнЙ=СбЗЙдбну™
Specifications
Dimensions: 31” x 21” x 16” (w x h x d)
(533mm x 787mm x 406mm)
Frequency Response: 20Hz to 120Hz +/- 1dB
16Hz to 180Hz -3dB, +2dB
Weight: 83.5 lbs (38 kg)
Inputs: High-level left and right with 5-way
binding posts;
Low-level left and right, single-ended
RCA and balanced XLR;
LFE low-level mono single-ended RCA
and balanced XLR
Outputs: LFE low-level mono buffered single-
ended RCA and balanced XLR
Controls: Variable low-pass filter
Variable bass gain control
Variable LFE gain control
Phase switch 0º, 180º
Finish: Basic Black or Automotive Finishes
