ASSEMBLY
Motor
Harness
Groove Groove
11
• Turn the vehicle over so that the bottom is facing up.
• Insert two #8 x
3 /
4
" screws through the slots in the vehicle
bottom and into the seat. Tighten the screws.
• Place the seat onto the vehicle floorboard, as shown.
• Insert two #8 x
3 /
4
" screws through the seat and into the floor-
board. Tighten the screws.
12
13
• Fit the motor harness into the groove in the vehicle floorboard,
as shown.
Seat
Slots Slots
BOTTOM VIEW
